12 x 1,27 = 15,24
1,27
1,27
17,46
18,46
19,26
1,8
3,25
5
4,2
ohne Verriegelung
7,35
Einzelheit X (M 2:1)
without interlocking
4
with interlocking
Verpackt in Tray
-tray packaging
Verpackungseinheit 44 Stück
-packaging unit 44
342
max.
4
mit Verriegelung
detail X
3 x 23,7 = 71,1
128
max.
23,7
X
Adapterstück für board-to-board Abstand von 30mm (beidseitig verbaut mit Federleiste: 154806, Low Profile)
Adapter for board-to-board height 30mm (in combination with two female connectors: 154806, low profile)
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Information:
Tolerances
All Dimensions
in mm
Scale
3:1
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
E01
Index
26.06.2008
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
1,27 DRC Adapterstück BTB 30mm
28,2
17,5
13,5
26-polig
www.ERNI.com
Class
364089
DRCBTB
I
A3
