ADNS-2700

Single Chip USB Optical Mouse Sensor

Data Sheet

Description

The ADNS-2700 is a compact, one chip USB optical mouse

sensor designed for implementation of a non-mechanical

tracking engine in computer mice.

It is based on optical navigation technology that measures

changes in position by optically acquiring sequential

surface images (frames) and mathematically determining

the direction and magnitude of movement.

The sensor is in an 8-pin optical package that is designed

to be used with the ADNS-5100-001 trim lens, LED clip

and the HLMP-EG3E-xxxxx LED. Together, these parts

provide a complete and compact mouse sensor. There

are no moving parts and precision optical alignment is

not required, thus facilitating high volume assembly.

The output format is USB. This device meets HID Revision

1.11 specification and is compatible with USB Revision 2.0

specification.

Frame rate is varied internally to the sensor to achieve

tracking and speed performance, eliminating the need for

the use of many registers.

Default resolution is specified as 1000 counts per inch,

with rates of motion up to 30 inches per second.

A complete mouse can be built with the addition of a PC

board, switches and Z-wheel, plastic case and cable.

Features



One chip USB mouse sensor



USB 2.0 Low Speed Compliance



12 bits USB motion data reporting



Meets HID Revision 1.11



Single 5.0 volts power supply



High speed motion detection at 30 inches per second

(ips) and acceleration up to 8 g



Input buttons: 3 buttons



Z-Wheel interface for vertical scroll



Integrated oscillator



Integrated USB D- pull-up resistor



Product string is set to “USB Optical Mouse”



On-chip OTP memory for device configuration

flexibility without any external software driver:

– Programmable resolution from 500 to 1250 counts

per inch (cpi) with 250 cpi step.

– Programmable sensor orientation

– Programmable VID and PID.

Applications



Corded optical mice



Trackballs



Integrated input devices

NOTE: ADNS-2700 will be referred to as "sensor", ADNS-5100-

001 as " trim lens" and HLMP-EG3E as "LED" hereafter.
