TX15-140P-LT-MH1E: DescriptionBoard Stacking Connector, 140 Contact(s), 2 Row(s), Male, Right Angle, Solder Terminal, Plug, LEAD FREE; CategoryThe connector The connector; File Size173KB，1 Pages; ManufacturerJapan Aviation Electronics Industry Limited; Environmental Compliance

Download Datasheet Parametric Compare View All

TX15-140P-LT-MH1E Overview

Board Stacking Connector, 140 Contact(s), 2 Row(s), Male, Right Angle, Solder Terminal, Plug, LEAD FREE

TX15-140P-LT-MH1E Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1668659240
package instruction	LEAD FREE
Reach Compliance Code	unknown
Body/casing type	PLUG
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	1.27 mm
Termination type	SOLDER
Total number of contacts	140
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

TX15-140P-LT-MH1E Related Products

	TX15-140P-LT-MH1E	TX15-140P-LT-MH2E	TX15-160P-LT-MH3E	TX15-180P-LT-MH2E	TX15-180P-LT-MH3E	TX15-200P-LT-MH2E
Description	Board Stacking Connector, 140 Contact(s), 2 Row(s), Male, Right Angle, Solder Terminal, Plug, LEAD FREE	Board Stacking Connector, 140 Contact(s), 2 Row(s), Male, Right Angle, Solder Terminal, Plug, LEAD FREE	Board Stacking Connector, 160 Contact(s), 2 Row(s), Male, Right Angle, Solder Terminal, Plug, LEAD FREE	Board Stacking Connector, 180 Contact(s), 2 Row(s), Male, Right Angle, Solder Terminal, Plug, LEAD FREE	Board Stacking Connector, 180 Contact(s), 2 Row(s), Male, Right Angle, Solder Terminal, Plug, LEAD FREE	Board Stacking Connector, 200 Contact(s), 2 Row(s), Male, Right Angle, Solder Terminal, Plug, LEAD FREE
package instruction	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
Body/casing type	PLUG	PLUG	PLUG	PLUG	PLUG	PLUG
Connector type	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR
Contact point gender	MALE	MALE	MALE	MALE	MALE	MALE
DIN compliance	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	NO
Mixed contacts	NO	NO	NO	NO	NO	NO
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of rows loaded	2	2	2	2	2	2
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Terminal pitch	1.27 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm
Termination type	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER
Total number of contacts	140	140	160	180	180	200
UL Flammability Code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
Maker	-	Japan Aviation Electronics Industry Limited	Japan Aviation Electronics Industry Limited	Japan Aviation Electronics Industry Limited	Japan Aviation Electronics Industry Limited	Japan Aviation Electronics Industry Limited
Manufacturer's serial number	-	TX15	TX15	TX15	TX15	TX15
