HLMA-Qx00, HLMA-Px00 HLMT-Px00 and HLMT-Qx00
Subminiature High Performance AlInGaP LED Lamps
Data Sheet
SunPower Series
HLMA-PF00, HLMA-PG00, HLMA-PH00, HLMA-PL00, HLMA-QF00, HLMA-QG00, HLMA-QH00,
HLMA-QL00, HLMT-PG00, HLMT-PH00, HLMT-PL00, HLMT-QG00, HLMT-QH00, HLMT-QL00
Description
Flat Top Package
The HLMX-PXXX flat top lamps use an untinted, nondif-
fused, truncated lens to provide a wide radiation pattern
that is necessary for use in backlighting applications. The
flat top lamps are also ideal for use as emitters in light
pipe applications.
Features
Subminiature flat top package
Ideal for backlighting and light piping applications
Subminiature dome package
Nondiffused dome for high brightness
Wide range of drive currents
Colors: 590 nm Amber, 605 nm Orange, 615 nm Red-
dish-Orange, 622/626 nm Red, and 635 nm Red
Ideal for space limited applications
Axial leads
Available with lead configurations for surface mount
and through hole PC board mounting
Dome Packages
The HLMX-QXXX dome lamps use an untinted, nondif-
fused lens to provide a high luminous intensity within a
narrow radiation pattern.
Lead Configurations
All of these devices are made by encapsulating LED chips
on axial lead frames to form molded epoxy submini-
ature lamp packages. A variety of package configuration
options is available. These include special surface mount
lead configurations, gull wing, yoke lead, or Z-bend. Right
angle lead bends at 2.54 mm (0.100 inch) and 5.08 mm
(0.200 inch) center spacing are available for through hole
mounting. For more information refer to Standard SMT
and Through Hole Lead Bend Options for Subminiature
LED Lamps data sheet.
Technology
These subminiature solid state lamps utilize one of the
two newly developed aluminum indium gallium phos-
phide (AlInGaP) LED technologies. The HLMT-Devices
are especially effective in very bright ambient lighting
conditions. The colors 590 nm amber, 605 nm orange,
615 nm reddish-orange, 622/626 nm red, and 635 nm red
are available with viewing angles of 15° for the domed
devices and 125° for the flat top devices.
Device Selection Guide
Part Number
HLMA-QL00
HLMT-QL00
HLMA-QJ00
HLMA-QH00
HLMT-QH00
HLMA-QG00
HLMT-QG00
HLMA-QF00
HLMA-PL00
HLMT-PL00
HLMA-PJ00
HLMA-PH00
HLMT-PH00
HLMA-PG00
HLMT-PG00
HLMA-PF00
d
(nm)
590
590
605
615
615
626
622
635
590
590
605
615
615
626
622
635
Typ. I
V
(mcd)
500
1000
500
500
800
500
1000
500
75
150
75
75
120
75
150
75
Package
Description
Domed,
Nondiffused,
Untinted
Viewing
Angle 2
1
/
2
15°
Package
Outline
B
Flat Top,
Nondiffused,
Untinted
125°
A
Absolute Maximum Ratings at T
A
= 25°C
Parameter
Peak Forward Current
[2]
Average Forward Current (I
PEAK
= 100 mA)
[1,2]
DC Forward Current
[3,5,6]
Power Dissipation
Reverse Voltage (I
R
= 100 μA)
Transient Forward Current (10 μs Pulse)
[5]
Operating Temperature Range
Storage Temperature Range
LED Junction Temperature
Lead Soldering Temperature [1.6 mm (0.063 in.) from body]
SMT Reflow Soldering Temperature
HLMA-xxxx
100
30
50
120
5
500
–40 to +100
–55 to +100
110
260°C for 5 seconds
260°C for 20 seconds
HLMT-xxxx
100
30
50
130
Unit
mA
mA
mA
mW
V
mA
°C
°C
°C
Notes:
1. Maximum I
AVG
at f = 1 kHz.
2. Refer to Figure 5 to establish pulsed operating conditions.
3. Derate linearly as shown in Figure 4.
4. The transient peak current is the maximum non-recurring peak current these devices can withstand without damaging the LED die and wire
bonds. Operation at currents above Absolute Maximum Peak Forward Current is not recommended.
5. Drive currents between 10 mA and 30 mA are recommended for best long term performance.
6. Operation at currents below 5 mA is not recommended, please contact your Avago sales representative.
2
Part Numbering System
HLMx - x x 00 - x x x xx
Packaging Option
00: Straight Leads, Bulk Packaging, Quantity of 500 parts
11: Gull Wing Bend, Tape & Reel – 7" Reel
12: Gull Wing Bend, Bulk
14: Gull Wing Bend, Tape & Reel – 13" Reel
21: Yoke Bend, Tape and Reel – 7" Reel
22: Yoke Bend, Bulk
24: Yoke Bend, Tape and Reel – 13" Reel
31: Z-Bend, Tape and Reel – 7" Reel
32: Z-Bend, Bulk
34: Z-Bend, Tape and Reel – 13" Reel
Color Bin Selection
0: Full Color Bin Distribution
B: Color Bins 2 & 3
K: Color Bins 2, 3 & 4
R: Color Bins 2 & 4
W: Color Bins 2, 4, 6 & 7
X: Color Bins 4, 6 & 7
Maximum Iv Bin Options
Please refer to the Iv Bin Table
Minimum Iv Bin Options
Please refer to the Iv Bin Table
Color Options
L: Amber 590 nm
J: Orange 605 nm
H: Reddish Orange 615 nm
G: Red 622/626 nm
F: Red 635 nm
Package Options
Q: Dome
P: Flat Top
3
Optical Characteristics at T
A
= 25°C
Total Flux
V
(mlm)
@ 20 mA
[2]
Typ.
250
250
250
250
250
250
250
250
800
250
250
250
250
800
800
250
250
800
250
250
250
250
250
800
250
250
800
250
800
250
Part Number
HLMA-QL00-S00xx
HLMA-QL00-TU0xx
HLMA-QL00-TUKxx
HLMA-QL00-TVBxx
HLMA-QL00-TVKxx
HLMA-QL00-UV0xx
HLMA-QL00-UVRxx
HLMA-QL00-UWBxx
HLMT-QL00-T00xx
HLMA-QJ00-S00xx
HLMA-QH00-S00xx
HLMA-QH00-T00xx
HLMA-QH00-UW0xx
HLMT-QH00-T00xx
HLMT-QH00-WX0xx
HLMA-QG00-S00xx
HLMA-QG00-TV0xx
HLMT-QG00-T00xx
HLMA-QF00-S00xx
HLMA-PL00-N00xx
HLMA-PL00-PRRxx
HLMA-PL00-PRXxx
HLMA-PL00-QRXxx
HLMT-PL00-P0Wxx
HLMA-PJ00-N00xx
HLMA-PH00-N00xx
HLMT-PH00-P00xx
HLMA-PG00-N00xx
HLMT-PG00-P00xx
HLMA-PF00-N00xx
Luminous Intensity
I
V
(mcd) @ 20 mA
[1]
Min.
Typ.
Max.
160
250
250
250
250
400
400
400
250
160
160
250
400
250
1000
160
250
250
160
25
40
40
63
40
25
25
40
25
40
25
500
–
–
–
–
–
–
–
1000
500
500
500
–
500
–
500
–
1000
500
75
–
–
–
150
75
75
120
75
150
75
–
800
800
1250
1250
1250
1250
2000
–
–
–
–
2000
–
3200
–
1250
–
–
–
200
200
200
–
–
–
–
–
–
–
Peak
Wavelength
peak
(nm)
Typ.
592
592
592
592
592
592
592
592
592
609
621
621
621
621
621
635
635
635
650
592
592
592
592
592
609
621
621
635
635
640
Color,
Dominant
Wavelength
d[3]
(nm)
Typ.
590
590
590
590
590
590
590
590
590
605
615
615
615
615
615
626
626
622
635
590
590
590
590
590
605
615
615
626
622
635
Viewing
Angle
2
1/2
Degrees
[4]
Typ.
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
125
125
125
125
125
125
125
125
125
125
125
Luminous
Efficacy
v[5]
(lm/w)
Typ.
480
480
480
480
480
480
480
480
480
370
263
263
263
263
263
150
150
150
110
480
480
480
480
480
370
263
263
150
150
110
Notes:
1. The luminous intensity, I
v
, is measured at the mechanical axis of the lamp package. The actual peak of the spatial radiation pattern may not be
aligned with this axis.
2.
v
is the total luminous flux output as measured with an integrating sphere.
3. The dominant wavelength,
d
, is derived from the CIE Chromaticity Diagram and represents the color of the device.
4.
1/2
is the off-axis angle where the liminous intensity is 1/2 the peak intensity.
5. Radiant intensity, I
e
, in watts/steradian, may be calculated from the equation I
e
= I
v
/
v
, where I
v
is the luminous intensity in candelas and
v
is
the luminous efficacy in lumens/watt.
5
