M4S
M4S
R
Characteristics
Electrostatic capacitance
Between open Contacts
Between coil & Contacts
Between Contact Poles
Insulation Resistance
Dielectric Strength
Between open Contacts
Between coil & Contacts
Between Contact Poles
Surge Withstand Voltage
Between open Contacts
Between coil & Contacts
Between Contact Poles
Shock resistance
1500V
1500V
1500V
Functional:100m/s
2
11ms;
2
Survival:1000 m/s 6ms
10~55Hz Double amplitude
Functional:1.5mm Survival:5mm
5N
235
2
3 0.5s
-40~90 (-40~194 F)
(-40~80 for 0.3W Coil)
4.5g
FCC68
FCC68
FCC68
IEC68-2-27 Test Ea
IEC68-2-6 Test Fc
IEC68-2-21 Test Ua1
IEC68-2-20 Test Ta method 1
Approx.0.7pF
Approx.1.0pF
Approx.0.9pF
1000M min (at 500VDC)
1000VAC 1min
1000VAC 1min
1000VAC 1min
Item 4.41 of IEC 61810-7
Item 4.41 of IEC 61810-7
Item 4.41 of IEC 61810-7
Item 7 of IEC 61810-5
Item 6 of IEC 61810-5
Item 6 of IEC 61810-5
Item 6 of IEC 61810-5
C
US
E169380
R50044268
20.0 9.8 12.0
Features
DIL Pitch Terminals .High Sensitivity
Conforms to FCC Part 68 1.5kV Surge and Dielectric 1000VAC
Fully sealed (immersion cleaning).
High Reliability bifurcated Contact.
Application for Telecommunication Equipment,Office Equipment,Security Alarm Systems,Measuring instruments,
Medical Monitoring Equipment,Audio Visual Equipment, Flight Simulator,Sensor Control
Ordering Information
M4S 12
1
2
H A
3
4
W
5
3 Enclosure H: Sealed Type
4 Nominal coil power Nil:0.15W A:0.2W
5 Contact material W: AgNi
Vibration resistance
Terminals strength
Solderability
Temperature Range
Mass
1 Part number M4S
2 Coil rated voltage DC:3:3V 5:5V 6:6V 9:9V
12:12V 18:18V 24:24V 48:48V
Contact Data
Contact Arrangement
Contact Material
Contact Rating (resistive)
Max. Switching Power
Max. Switching Voltage
Contact Resistance or
Voltage drop
Operational
life
Electrical
Mechanical
2C DPDT(B-M)
AgNi(Gold clad
1mA/10mV to 2A,3A/30VDC; 0.6A/125VAC
90W 125VA
Min. Switching load 1mA/10mV
220VDC 250VAC
Max. Switching Current:3A
100m
1
10
8
10
5
Item 4.12 of IEC 61810-7
Safety approvals
Reference Value
Safety approval
Load
UL&CUR
2A,3A/30VDC 0.6A/125VAC
T
U
V
2A/30VDC
0.6A/125VAC
Dimensions
Item 4 .30 of IEC 61810-7
Item 4.31 of IEC 61810-7
20max.
0.787max.
9.8max.
0.386max.
1
4
6
8
mm/inch
CAUTION:
Coil Parameter
Dash
numbers
Coil voltage
VDC
Rated
3
5
6
9
12
18
24
48
3
5
6
9
12
24
48
Max
7.5
12.5
15.0
22.5
30.0
40.0
52.9
84.9
6.5
10.8
13.0
19.5
26.5
52.9
103.9
Coil
resistance
10%
60
167
240
540
960
1620
2880
7680
45
125
180
405
720
2880
11520
Pick up voltage
VDC(max)
(70% of rated voltage )
2.1
3.5
4.2
6.3
8.4
12.6
16.8
33.6
2.1
3.5
4.2
6.3
8.4
16.8
33.6
Release voltage
VDC(min)
(5% or 10% of
rated voltage)
0.15
0.25
0.3
0.45
0.6
0.9
1.2
2.4
0.3
0.5
0.6
0.9
1.2
2.4
4.8
Coil
power
W
0.15
0.15
0.15
0.15
0.15
0.20
0.20
0.30
0.2
0.2
0.2
0.2
0.2
0.2
0.2
12max.
0.472max.
3.5
0.138
Relays previously tested or used above 10mA resistive at 6VDC maximum or peak AC open circuit are not
recommended for subsequent use in low level applications.
Operate
Time
ms
Release
Time
ms
0.5
0.787
1.11
0.044
7.62
0.30
5.08
0.20
5.08
0.20
16
13
11
9
M4S-003
M4S-005
M4S-006
M4S-009
M4S-012
M4S-018
M4S-024
M4S-048
M4S-003A
M4S-005A
M4S-006A
M4S-009A
M4S-012A
M4S-024A
M4S-048A
0.25
0.01
7.62
0.30
2.54
0.1
Wiring diagram
(Bottom view)
2.54
0.1
Approx. 5 Approx. 3
Dimensions
Approx. 5 Approx. 3
8- 0.8
0.031
Tolerance: 0.1/
0.004
Mounting (Bottom view)
NOTES 1).Dimensions are in millimeters.
2).Inch equivalents are given for general information only.
CAUTION:
1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release voltage are for test purposes only, and are not to be used as design criteria.
41
Ningbo Huaguan Electronics Corporation LTD.
