1. DIMENSIONING AND TOLERANCING PER ASME Y14.5M, 1994 .
2. CONTROLLING DIMENSION: MILLIMETERS.
3. DIMENSION b APPLIES TO PLATED TERMINAL AND IS
MEASURED BETWEEN 0.25 AND 0.30 MM FROM TERMINAL.
4. COPLANARITY APPLIES TO THE EXPOSED PAD AS WELL AS
THE TERMINALS.
DIM
A
A1
A3
b
D
D2
E
E2
e
K
L
MIN
0.70
0.00
0.25
1.40
0.90
0.35
MILLIMETERS
NOM
MAX
0.75
0.80
0.05
0.20 REF
0.30
0.35
2.00 BSC
1.50
1.60
2.00 BSC
1.00
1.10
1.30 BSC
0.35 REF
0.40
0.45
MIN
0.028
0.000
0.010
INCHES
NOM
0.030
MAX
0.031
0.002
0.014
0.063
0.043
0.018
D
A
B
PIN ONE
REFERENCE
E
2X
0.10 C
2X
0.008 REF
0.012
0.079 BSC
0.055
0.059
0.079 BSC
0.035
0.039
0.051 BSC
0.014 REF
0.014
0.016
0.10 C
0.10 C
8X
0.08 C
SEATING
PLANE
A1
2X
L
K
0.400
1.600
E2
