Array
Feature
•Reducing
SMD surface area (40% reduced).
•Reducing
SMD costs (75% reduced).
•Both
flow and reflow soldering are applicable.
•Convex
& concave type.
The product of lead-free terminal is RoHS compliant.
PhO(lead oxide) is included in the glass of our product which is prescribed
on RoHS appendix as an exception.
Application
•For
semiconductor devices.
•For
computers, digital circuits.
Structure and Dimensions
(1) CONVEX TERMINAL TYPE
•2
Array
A
T
•4
Array
A
D
T
W
B
123
B
P
L
W
P
L
G
G
(UNIT: mm)
Type
RP102P
RP104P
RP164P
L
1.00
±0.10
2.00
±0.10
3.20
±0.10
W
1.00
±0.10
1.00
±0.10
1.60
±0.10
T
0.35
±0.10
0.35
±0.10
0.50
±0.10
A
0.33
±0.05
0.30
±0.15
0.40
±0.15
D
-
0.40
±0.15
0.60
±0.15
B
0.20
±0.10
0.15
±0.10
0.30
±0.15
G
0.25
±0.10
0.25
±0.15
0.30
±0.15
P
0.65
±0.10
0.50
±0.15
0.80
±0.15
Average
Weight
1.1㎎
2.2㎎
8.9㎎
(2) CONCAVE TERMINAL TYPE
•2
Array
A
B
(Top side)
T
•4
Array
A
B
W
T
10 0
P
L
10 0
P
L
W
(Bottom side)
G
G
(UNIT: mm)
Type
RN102P
RN104P
RN162P
RN164P
L
1.00
±0.10
2.00
±0.10
1.60
±0.10
3.20
±0.10
W
1.00
±0.10
1.00
±0.10
1.60
±0.10
1.60
±0.10
T
0.35
±0.10
0.40
±0.10
0.60
±0.10
0.60
±0.10
A
0.30
±0.10
0.30
±0.10
0.45
±0.10
0.45
±0.10
B
0.15
±0.10
0.15
±0.10
0.30
±0.15
0.30
±0.15
G
0.25
±0.15
0.25
±0.15
0.40
±0.15
0.40
±0.15
P
0.5
±0.10
0.5
±0.10
0.80
±0.10
0.80
±0.10
Unit
Weight
1.2㎎
2.8㎎
4.7㎎
9.9㎎
Parts Numbering System
•The
part number system shall be in the following format
RN
Code Designation
16
Dimension
4P
Resistors
J
Tolerance
100
Resistance Value
FS
Packaging Code
CS : Tape Packaging 7"
ES : Tape Packaging 10"
FS : Tape Packaging 13"
AS : Tape Packaging 13"
RP: Convex type array
RN: Concave type array
10: 1005
16: 1608
2P: 2 Pieces
4P: 4 Pieces
J:
±5%
※
Jumper:’
J’
3 digit coding system
(IEC coding system)
E-24 series
Operation
Notes
Specification
Type
102P, 104P
162P, 164P
Power
Rating
(W)
1/16
Working Overload
Voltage Voltage
(MAX)
(MAX)
25(V)
50(V)
50(V)
100(V)
TCR (ppm/
℃
)
±250ppm
±200ppm
Resistance
Range (
Ω
)
1Ω~1MΩ
Rated
Rated
Working
Ambient
Temperature Temperature
70℃
-55℃~+125℃
Example of Land
Pattern Design
Recommended
Soldering Conditions
•
Rated voltage (V) =
Rated power(W)×Normal resistance value (R)
Rated voltage should be lower than (MAX) working voltage.
General
Purpose
√
Power Derating Curve
The rated power is the maximum continuous loading power at 70
℃
ambient temperature.
For ambient temperature above 70
℃
, the loading power follows the below power derating curve.
(The load current shall be derated according to Derating curve in case of the 'Jumper')
100
Percentage of the rated
dissipation(%)
80
60
Operation area
40
20
0
-55
-40
0
40
70
125
Precision
Low Ohms
Array
80
120
Ambient Temperature(℃)
Attenuator
Jumper Resistors
Type
102P, 104P
162P, 164P
Characteristics
Performance
Resistance
50mΩMax.
Current Rating
1.0(A)
Rated Ambient
Temperature
70℃
Rated Working
Temperature
-55℃~+125℃
Packaging
Marking
•
3 digits indication(E-24 series)
- Left 2 digits represent significant figures.
- Last 1 digit represents exponential number of 10.
- Example:
103
Left 2 digit:
10
Last 1 digits:
3
103
=
10×10
3
=10000Ω=10kΩ
Standard
Resistance Value
103
※
Jumper chip is printed
as “000”.
•
RP102P, RN102P, RN104P type : No marking.
Design and Specifications are subject to change without prior notice.
Please ask the manufacturer for technical Specifications before you order and/or use.
