06
COM Express CPU Modules
TPM
BIOS
COM-KB
COM Express Type 6 with AMD® G-Series SoC APU
DDR3/3L SODIMM Socket
eDP Connector
ITE 8518 I/O
Controller
AMD® Embedded
G-Series SoC APU
Realtek RTL8111E Gigabit
Ethernet
Embedded G-Series SoC APU:
- AMD® GX-420CA Quad-core 2.0 GHz SoC with AMD
Radeon™ HD 8400E Graphics
- AMD® GX-217GA Dual-core 1.65 GHz SoC with AMD
Radeon™ HD 8280E Graphics
■
■
DDR3/DDR3L-1600 MHz SODIMM, Up to 8 GB
■
■
Gigabit Ethernet x 1
■
■
CRT, 24-bit Single Channel LVDS
■
■
High Definition Audio Interface
■
■
SATA x 2, USB3.0 x 2, USB2.0 x 8
■
■
PCI-Express [x1] x 5
■
■
COM Express Pin out Type 6
■
■
Compact Module Size, 95mm x 95mm, COM.0 Rev. 2.0
■
■
AMD®
Features
Specifications
System
Form Factor
COM Express compact module, Pin-out type 6, COM. 0 Rev.2.0
AMD® Embedded G-Series SoC APU
GX-420CA SoC with AMD Radeon™ HD 8400E Graphics (Quad-core, 25W TDP,
CPU freq. 2.0 GHz, GPU freq. 600 MHz)
GX-217GA SoC with AMD Radeon™ HD 8280E Graphics (Dual-core, 15W TDP,
CPU freq. 1.65 GHz, GPU freq. 450 MHz)
204-pin DDR3/DDR3L 1600 MHz SODIMM, Up to 8 GB (non-ECC support)
AMD® Embedded G-Series SoC
ITE 8518 I/O controller
Realtek RTL8111E , 10/100/1000Base-TX, RJ-45 x 1
—
AMI Plug & Play SPI BIOS – 16 MB ROM
Atmel AT24C02 (2Kb), Save BIOS and configuration data (Optional)
Yes
ITE 8518 , 255 levels
Supports CPU temperature monitoring
PCI-Express [x1] x5, LPC bus x 1, SMBUS x 1, PCI-Express[x4] x 1(PEG) , DDI x 2
+12V AT/ATX
AMD GX-420CA 2.0 GHz, DDR3L 8 GB, 1.2A@+12V
3.74” x 3.74” (95mm x 95mm)
0.55 lb (0.25 kg)
32 °F ~ 140 °F (0 °C ~ 60 °C)
-4 °F ~ 158 °F (-20 °C ~ 70 °C)
10% ~ 80% relative humidity, non-condensing
80,000
AMD® Embedded G-Series SoC APU
GX-420CA SoC with AMD Radeon™ HD 8400E Graphics (Quad-core, 25W TDP,
CPU freq. 2.0 GHz, GPU freq. 600 MHz)
GX-217GA SoC with AMD Radeon™ HD 8280E Graphics (Dual-core, 15W TDP,
CPU freq. 1.65 GHz, GPU freq. 450 MHz)
1920 x 1200 @ 60 Hz for CRT
1400 x 1050 @ 60 Hz for LCD
1920x 1080 for HDMI
1920x 1080 for eDP
24-bit single channel LVDS
—
SATA x 2
USB3.0 x 2, USB2.0 x 8
High definition audio interface
Up to 4 in and 4 out
Packing List
•
M2.5 Screw x 5
•
Product CD
•
COM-KB
Processor
System Memory
Chipset
I/O Chipset
Ethernet
Optional Accessory
•
ECB-920A-A10
COM Express Type 1/6/10 Carrier Board, Gigabit Ethernet, USB, 2 COM, 4 SATA, PCIe, AT/ATX, Legacy Free,
Rev. A1.0
EEPROM
Wake on LAN
Watchdog Timer
H/W Status Monitoring
Expansion Interface
Power Requirement
Power Consumption
Board Size
Gross Weight
Operation Temperature
Storage Temperature
Operation Humidity
MTBF
•
TF-PER-A127
Heat Spreader, For COM-KB
•
TF-PER-A118
CPU Cooler, 35Watt, For COM Express Size, To be used with Heat Spreader
Display
Chipset
Graphic Engine
Resolution
LCD Interface
SDVO
I/O
Storage
USB
Audio
GPIO
06-9
www.aaeon.com
