ATTENUATORS
7/16 - DIN, up to 3 GHz, 100 Watts
SPECIFICATIONS:
Models: XD100W-XX, XD100W-XXF & XD100W-XXM
Electrical:
Frequency Range
Standard Freq. Values
Standard dB Values
Attenuation Accuracy
3 & 6 dB
10 dB
20 & 30 dB
40 dB
VSWR (Max.)
Input Power
Output Power
Peak Power
Impedance
Operating Temp Range
DC - 6.0 GHz
2.5 & 6 GHz
3, 6, 10, 20, 30 & 40 dB
2.5 - 6 GHz
1.5 - 2.5 GHz
±0.50 dB
±0.75 dB
±0.75 dB
±2.50 dB
±0.75 dB
±1.50 dB
±1.50 dB
±2.50 dB
1.35:1
1.45:1
100 Watts Avg. @ +25°C
Derated Linearly to 20 Watts @ +1
o
C
25
DC - 1.5 GHz
±0.50 dB
±0.75 dB
±0.75 dB
±1.50 dB
1.25:1
Custom Mtg. hole Config.
may be Added to this
Surface
3.46±.02
[87.88±0.51]
SQUARE
20 Watts
1 kW Max.
(5uSec Pulse, .05% Duty Cycle)
50 Ohms
-55°C to +1
25°C
Mechanical:
7/16 - DIN Connectors
Mates with DIN 47 223
END VIEW
TYPICAL
Units must be Mounted in such a way as to
Allow for Free Air Flow Around fins to Assure
Performance
Silver Plated Brass
Silver Plated Beryllium Copper
Anodized Aluminum
Conductors
Housing
Note: Units are Unidirectional, Therefore Input Connector MUST be Specified & will be Indicated on Unit
Model Number:
XD100W-XX
Male/Female Connectors
Length: 7 1 ±.08 [188.2 ±2.0]
.4
Pictured
7.41±.08
[188.24±2.03]
1.75 [44.45]
Model Number:
XD100W-XXF
Female/Female Connectors
Length: 7 ±.08 [191.8 ±2.0]
.55
INPUT
Model Number:
XD100W-XXM
Male/Male Connectors
Length: 7 ±.08 [184.7 ±2.0]
.27
.23 [5.84]
2X 8-32UNC-2B TAP
x .50 [12.7] DP.
2X M4x0.7 TAP
x .50 [12.7] DP.
HOW TO ORDER:
Model Number:
Ordering Examples:
Model Number:
2D100W-30
DC - 2.5 GHz, 30 dB; 7/16 - DIN, Male/Fem
Connector Configuration
= Male/Female
(Male Input)
F = Fem/Fem
M = Male/Male
FM = Female/Male
(Female Input)
Model Number:
2D100W-03F
DC - 2.5 GHz, 3 dB; 7/16 - DIN, Fem/Fem
Model Number:
6D100W-20FM
DC - 6 GHz, 20 dB; 7/16 - DIN, Female/Male
XD100W-XXY
Freq. Range
2 = DC - 2.5 GHz
6 = DC - 6 GHz
dB Value
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design specifications are subject to change without notice.
Contact factory for technical specifications before purchasing or use.
XD100W-ATT: REV L
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex-inmet.com • inmetsales@aeroflex.com
