TRG150 Series
EXTERNAL POWER SUPPLY
1 5 0 W AT T S - A C / D C G E N E R A L S I N G L E O U T P U T
FEATURES
•
•
•
•
•
•
•
•
•
Wide input voltage
Continuous short circuit protection
Over voltage protection
Output voltage available from 12VDC to 48VDC
High efficiency 85% typical
Meets EN55022 Class ”B”, conducted emissions
MEPS compliance (Efficiency Mark V pending)
ROHS compliance
Active PFC function
SPECIFICATIONS
INPUT
STANDARDS AND APPROVALS
Voltage range
Frequency
Inrush current
Isolation
Leakage current
OUTPUT
90 to 264Vac
47Hz to 63Hz
120A max @ 264Vac
Input to Output 4,242Vdc
3.5mA max.
Factory preset, see table (not adjustable)
+/-2% (60% load)
2% p-p max
Continuous (Auto recovery)
8ms typ @ 115Vac
+5% (20% to 160% load)
+/-1% max 100Vac to 240Vac at full load
0°C to +60°C
Derate from 100% at 40°C linearly to 60% at
60°C
-20°C to +85°C
Safety standards
Queensland Electrical Safety Office
Certificate of approval Qld Q090086,
AS/NZS 609050.1:203, EN60950
AS/NZS CISPR 11:2002 Group 1
Meets EN55022 Class B and CISPR/FCC Class B
Complies with AS/NZS 4417 Parts 1,2,3 N911
180 x 74 x 41mm
IEC320/C14
Right angle, hollow barrel connector, 2.5mm
inside diameter; 5.5mm outside diameter;
9.5mm length Center positive polarity.
68AWG/UL2464
C-tick
EMI standards
RCM
MECHANICAL
Output voltage
Voltage set-point
Ripple and noise
Short circuit protection
Hold-up time
Load regulation
Line regulation
ENVIRONMENTAL
Dimensions
AC Inlet
Output connector
Over voltage protection Recycle AC input to Restart
DC cord length
SELECTION TABLE
Consult Powerbox for variation of output connector and DC Cord Lengths
RATED
VNOM
MAX
POWER
Operating temperature
Load Derating
Storage temperature
MODEL NUMBER
OUTPUTCURRENT
TRG150A120 - 21E11
TRG150A150 - 21E11
TRG150A240 - 21E11
TRG150A480 - 21E11
12Vdc
15Vdc
24Vdc
48Vdc
12.5A
10A
6.25A
3.13A
150W
150W
150W
150W
TECHNICAL ILLUSTRATION
288
Doc. No. PBC9 Rev.C 28-4-11
