PBAMR3 Series
36 WATTS - AC/DC DIN RAIL MOUNTABLE - INDUSTRIAL CONTROL
FEATURES
•
•
•
•
•
•
AC/DC Power Module
Universal Input 90~264VAC
High Efficiency up to 84%
Short Circuit Protection
Internal Input Filter
Low Profile for Building Automation
AC/DC DIN RAIL MOUNTABLE
AC/DC DIN RAIL MOUNTABLE
SPECIFICATIONS
INPUT
Input voltage range
Line frequency
Inrush current
OUTPUT
Cooling
AC in 90-264VAC
DC in 120-370VDC
47-63Hz
Vi: 115VAC 20-25A
Vi: 230VAC 40-50A
Free air Convection.
L91 x W53 x D56.2 mm
75% - 84% typical, model dependant
190g
UL508 Listed
UL1310 Class 2 power supply, UL60950-1
Recognised
EN60950-1
EN6100-3-2, EN61000-3-3, EN61000-6-2,
EN55024, EN61000-4-2, EN61000-4-3,
EN61000-4-4, EN61000-4-5, EN61000-4-6,
EN61000-4-8, EN61000-4-11, EN61204-3
AS/NZ CISPR11 Group 1, Class A
EN61000-6-3, EN55022 Class B
Dimension
GENERAL
Efficiency
Weight
STANDARDS
Output voltage accuracy
Minimum load
Line regulation
Load regulation
Ripple and noise
Hold up time
ENVIRONMENTAL
+1%
Not required.
+1%
+1%
BW = 20MHz, 50mV
Vi = 115VAC, lo nom 20 ms
Vi = 230VAC, lo nom 100 ms
UL/cUL
TUV
CE
C tick
Non Operational -25 to +85°
min 20% max 95%
T2A / 250VAC internal
110 - 150% of Vi nom
Input / Output 3,000VAC
Input-Output at 500VDC 100MΩ
-25°C to +71°C
From +56°C to +71°C, 2.5% per °C
EMI standards
Storage temperature
Relative humidity
Input fuse
Rated over load proection
Isolation voltage
Isolation resistance
Ambient temperature
Derating
SELECTION TABLE
MODEL NUMBER
OUTPUT
POWER
PBAMR3-05
PBAMR3-12*
PBAMR3-15
PBAMR3-24*
*Non indent item
+ 5 VDC
+ 12 VDC
+ 15 VDC
+ 24 VDC
4500mA
2700mA
2400mA
1500mA
22.5 WATTS
33 WATTS
36 WATTS
36 WATTS
MECHANICAL & PIN CONFIGURATION
Doc. No. PBC9 Rev.C 28-4-11
Powering Progress – www.powerbox.com.au
