XC9110E251MR-G datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> XC9110E251MR-G

XC9110E251MR-G: DescriptionSwitching Regulator/Controller, Voltage-mode, 85kHz Switching Freq-Max, CMOS, PDSO5; CategoryPower/power management The power supply circuit; File Size2MB，35 Pages; ManufacturerTOREX; Websitehttp://www.torex.co.jp/chinese/; Environmental Compliance

Download Datasheet Parametric View All

XC9110E251MR-G Overview

Switching Regulator/Controller, Voltage-mode, 85kHz Switching Freq-Max, CMOS, PDSO5

XC9110E251MR-G Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	110336973
package instruction	TSOP, TSOP5/6,.11,37
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR
control mode	VOLTAGE-MODE
Control Technology	PULSE FREQUENCY MODULATION
Maximum input voltage	10 V
Minimum input voltage	0.9 V
Nominal input voltage	1.5 V
JESD-30 code	R-PDSO-G5
JESD-609 code	e3
length	2.9 mm
Humidity sensitivity level	1
Number of functions	1
Number of terminals	5
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	0.0125 A
Package body material	PLASTIC/EPOXY
encapsulated code	LSSOP
Encapsulate equivalent code	TSOP5/6,.11,37
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Certification status	Not Qualified
surface mount	YES
Switch configuration	BOOST
Maximum switching frequency	85 kHz
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.95 mm
Terminal location	DUAL
width	1.6 mm

Preview

Download Datasheet

View All

XC9110/XC9111

Series

PFM Controlled Step-Up DC/DC Converter / Controller ICs

ETR0406-008

■GENERAL

DESCRIPTION

The XC9110/9111 series is a group of PFM controlled step-up DC/DC converter/controller ICs designed to generate low supply

voltage by the combination of PFM control and CMOS structure. The series is ideal for applications where a longer battery life is

needed such as in portable communication equipment. With a built-in 2.5ΩN-channel driver transistor, the XC9110A/C/E and

XC9111A/C/E types provide a step-up operation by using only a coil, a capacitor, and a diode connected externally.

The XC9110/9111B, D and F versions can be used with an external transistor for applications requiring larger currents.

Output voltage is internally programmable in a range from 1.5V to 7.0V in increments of 0.1V (accuracy:

2.5%).

Maximum oscillation frequency is set to 100kHz for XC9110/9111 series. (At light loads, it is set to 180kHz for the XC9111 series.)

Options include products equipped with a CE pin (C and D versions) that allows the IC to be shut down thereby reducing

supply current and with separated V

OUT

pins (E and F versions) to separate the power supply block and the output voltage

detect block. With the XC9110 series, maximum duty cycle is set to 75% (V

=3.3V) making it suitable for use with large

current operations. The XC9111 series automatically switches duty ratio between 56% & 75% (V

=3.3V) when it senses

changes in load to drop output ripple voltage and can support both large and small currents. The external transistor types

(B/D/F types) can be provided for applications, which require larger currents.

■APPLICATIONS

●Smart

phones / Mobile phones

●Note

PCs / Tablet PCs

●Digital

still cameras / Camcorders

●Mobile

devices / terminals

■

FEATURES

Input Voltage Range

: operating hold voltage 0.7V~10.0V

Start-up voltage

0.9V~10.0V

Output Voltage Range

: 1.5V~7.0V in 0.1V increments

Output Accuracy

: ±2.5%

Max Oscillation Frequency

: 100 kHz ±15%

180 kHz (at 56% duty of XC9111)

Built-in Switch Types

: A/C/E type

N-ch FET On-Resistance

: 2.5Ω V

=3.0V

External Transistor Types

: B/D/F type

Lx Limit Voltage

: E type: more than V

=2.0V

: A/C type: more than V

OUT

=2.0V

Max Duty Cycles

: 75% (for XC9110)

: 56%/75% two steps (for XC9111)

Low Supply Current

: 2.0μ @ V

OUT

=3V

Operating Ambient Temperature:

-40℃ ~ +85℃

Packages

: SOT-23, SOT-89 (for XC9111),

SOT-25, USP-6C

■TYPICAL

APPLICATION CIRCUIT

●C

type circuit

■

TYPICAL PERFORMANCE

CHARACTERISTICS

XC9111E331MR

L=100μH(CR54), CL47μF(Tantalum)

SD: XBS104S14R-G

100

(TOP VIEW)

SOT-25

VIN +

CIN

Efficiency:EFFI(%)

VOUT

3.0V

1.5V

1.2V

VIN=0.9V

2.4V

(Tantalum)

GND

1 00

150

2 00

Output Current:IOUT(mA)

250

3 00

1/35
