RoHS
Multilayer Chip Inductors
Dimensions:
Inches
(mm)
0.063±0.008
(1.60±0.2)
MLC05
0.031±.008
(0.80±0.2)
0.031±0.008
(0.80±0.2)
0.012±0.008
(0.30±0.20)
.070~.079
(1.8~.2.0)
.024~.032
(0.6~0.8)
.028~.031
(0.7~0.8)
Allied
Part
Number
Inductance
(µh)
Tolerance
(%)
Q
Min.
*
.033
.047
.056
.068
.082
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
22
M
M
M
M
M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
K,M
15
15
15
15
15
25
25
25
25
25
25
25
25
25
25
25
25
35
35
35
35
35
35
35
35
35
35
35
30
30
30
20
20
Test
Freq.
(MHz)
SRF
Min.
(MHz)
DCR
Max.
(Ω)
IDC
Max.
(mA)
Features
• 0603 EIA Size
• MultiLayer Ferrite Construction
• Closed Magnetic path for Shielding
• Excellent Solderability Characteristics
Electrical
Inductance Range:
.033µh to 22µh
Tolerance:
As noted, please indicate letter
desired tolerance.
Test Frequency:
As noted.
Operating Temp:
-40ºC ~ 125ºC / -55ºC to
+125ºC pending.
Resistance to Solder Heat
Pre-Heat: 150ºC, 1 minute.
Solder Composition: Sn/Ag3.0/Cu0.5
Solder Temp: 260ºC ±5ºC
Immersion time: 10 ±1 sec.
No Damage with more than 75% coverage.
Inductance within 30% of initial value. Within
20% over 12µh.
MLC05-R033M-RC
MLC05-R047M-RC
MLC05-R056M-RC
MLC05-R068M-RC
MLC05-R082M-RC
MLC05-R10_-RC
MLC05-R12_-RC
MLC05-R15_-RC
MLC05-R18_-RC
MLC05-R22_-RC
MLC05-R27_-RC
MLC05-R33_-RC
MLC05-R39_-RC
MLC05-R47_-RC
MLC05-R56_-RC
MLC05-R68_-RC
MLC05-R82_-RC
MLC05-1R0_-RC
MLC05-1R2_-RC
MLC05-1R5_-RC
MLC05-1R8_-RC
MLC05-2R2_-RC
MLC05-2R7_-RC
MLC05-3R3_-RC
MLC05-3R9_-RC
MLC05-4R7_-RC
MLC05-5R6_-RC
MLC05-6R8_-RC
MLC05-8R2_-RC
MLC05-100_-RC
MLC05-120_-RC
MLC05-150_-RC
MLC05-220_-RC
50
50
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4
4
4
2
2
1
1
270
260
255
250
245
240
205
180
165
150
136
125
110
105
95
85
75
65
60
55
50
45
40
38
36
33
22
20
18
17
15
14
11
0.20
0.30
0.30
0.30
0.30
0.50
0.50
0.60
0.60
0.80
0.80
0.85
1.00
1.35
1.50
1.70
2.10
0.60
0.80
0.80
0.95
1.10
1.30
1.50
1.70
2.10
1.50
1.70
2.10
2.55
2.60
1.50
1.70
50
50
50
50
50
50
50
50
50
50
50
35
35
35
35
35
35
25
25
25
25
15
15
15
15
15
5
5
5
5
3
1
1
Test Equipment
(L):
HP4291A RF Impedance Analyzer
or alternate.
DCR:
Chen Hwa 502BC or HP4338B
or alternate.
SRF:
HP8753D / Agilent E4991A
or alternate.
IDC:
HP4284A with HP42841A / HP4285A
with HP42841A.
Physical
Packaging:
4000 pieces per
7 inch
reel.
Marking:
None
*Please insert the letter for desired tolerance: K=10% M=20%
All specifications subject to change without notice.
949-356-1780
ALLIED COMPONENTS INTERNATIONAL
Revised 09/30/15
www.alliedcomponents.com
