RoHS
SMD Common Mode Choke
Dimensions:
Inches
(mm)
ACM6460
1
2
3
4
Allied
ACM6460-102E
DATE CODE
2
1
4
3
Features
Allied
Part
Number
Inductance
35%±/-25%
(uH)
DCR
(MaxΩ)
Rated
Current
Max
Leakage
Inductance.
Typical (uH)
(mA)Max
• Toroidal Design
• Flat top ideal for auto placement
• Excellent coplanarity of the terminals
• Turns Ratio within 1%
ACM6460-101E
ACM6460-151E
ACM6460-221E
ACM6460-331E
ACM6460-501E
ACM6460-751E
ACM6460-102E
ACM6460-122E
ACM6460-182E
ACM6460-222E
ACM6460-332E
ACM6460-502E
ACM6460-752E
ACM6460-103E
100
150
220
330
500
750
1000
1200
1800
2200
3300
5000
7500
10000
.006
.010
.012
.017
.024
.035
.049
.068
.106
.150
.210
.320
.640
.900
7.00
5.50
5.00
4.00
3.30
2.70
2.20
1.70
1.40
1.10
0.85
0.70
0.44
0.33
0.7
1.0
1.4
1.8
2.2
3.0
4.0
5.0
5.5
7.0
9.5
14.0
22.0
29.0
Electrical
Impedance range:
100uH to 1000uH
Test Frequency:
10Khz, .25v
Tolerance:
-35%±25%
Turns Ratio:
1:1 (1-2 : 4-3)
Operating Temp:
-55ºC ~ +105ºC
Test Equipment
(L):
HP4284
(L/L):
HP4284A
(T/R):
GKT-3250
(DCR):
GKT-502BC
Current:
VR 7220
All specifications subject to change without notice.
Schematic
Physical
4
1
N1
3
N2
2
Packaging:
350 per Tape and Reel
Marking:
ALLIED
ACM6460-xxxE
Date Code
: START
949-356-1780
ALLIED COMPONENTS INTERNATIONAL
01/22/2015
15
www.alliedcomponents.com
