Crystal oscillator
CRYSTAL OSCILLATOR
LOW-JITTER SAW OSCILLATOR
EG - 2002CA
•Frequency
range
:
62.5 MHz to 170 MHz
•Operating
voltage
:
3.3 V
•Output
:
LV-TTL
•Function
:
Output enable(OE)
•Thickness
:
1.2 mm Typ.
•Lead(Pb)-free
:
Lead free completely
•Very
low jitter and low phase noise by SAW unit.
Actual size
Specifications (characteristics)
Item
Output frequency range
Supply voltage
Storage temperature
Temperature
range
Operating temperature
Frequency tolerance
Current consumption
Output disable current
Symmetry
High output voltage
Low output voltage
Output load condition
High input voltage
Low input voltage
Output rise and fall time
Oscillation start up time
Jitter
*2
Symbol
f
0
V
CC
T_stg
T_use
F_tol(osc)
I
CC
I_dis
SYM
V
OH
V
OL
L_CMOS
V
IH
V
IL
tr / tf
Specifications
62.500 MHz to 170.000 MHz
3.3 V
±
0.3 V
-40
°C
to +100
°C
0
°C
to +70
°C
±50 ×
10
-6
,
±100 ×
10
-6
60 mA Max.
25 mA Max.
45 % to 55 %
2.4 V Min.
0.4 V Max.
25 pF Max.
15 pF Max.
70 % V
CC
Min.
30 % V
CC
Max.
1.5 ns Max.
10 ms Max.
0.2 ps Typ.
3 ps Typ.
3 ps Typ.
25 ps Typ.
4 ps Typ.
0.05
×
10
-3
UI Typ.
1 ps Max.
±
5
×
10
-6
/ year Max.
Remarks
Please contact us for inquiries regarding available frequencies.
Stored as bare product after unpacking
0
°C
to +70
°C
*1
OE=V
CC
, No load condition
OE=GND
1.4 V level, L_CMOS
≤
Max.
I
OH
= -8 mA
I
OL
= 8 mA
f
0
= 62.5 MHz
f
0
> 62.5 MHz
OE terminal
OE terminal
0.8 V
→
2.0 V level, L_CMOS
≤
Max.
Time at minimum supply voltage to be 0 s
Deterministic Jitter
Random Jitter
σ
(RMS of total distribution)
Peak to Peak
Accumulated Jitter(σ) n=2 to 50000 cycles
Offset frequency: 12 kHz to 20 MHz
Phase Jitter
t
OSC
t
DJ
t
RJ
t
RMS
t
p-p
t
acc
t
PJ
Frequency aging
*3
F_aging
+25
°C,First
year,V
CC
=3.3 V
*1
As per below table
*2
Based on DTS-2075 Digital timing system made from WAVECREST with jitter analysis software VISI6.
*3
Except : PCH,DCH
Frequency range (MHz)
P: 125 to 170
D: 62.5 to 124.999
H:
±100×10
-6
(0
°C
to +70
°C)*4
PCH
DCH
Details of
Y:
±100×10
-6
(0
°C
to +70
°C)
*5
PCY
DCY
frequency
Z:
±50×10
-6
(0
°C
to +70
°C)*6
PCZ
DCZ
tolerance
-6
F:
±50×10
(0
°C
to +70
°C)*5
PCF (125 MHz Only)
-
*4
This includes initial frequency tolerance, temperature variation, supply voltage variation, load variation, reflow drift, and 10 years aging(+25
°C,10
years).
*5
This includes initial frequency tolerance, temperature variation, supply voltage variation, load variation, and reflow drift (except 10 years aging).
*6
This includes initial frequency tolerance and temperature variation (except supply voltage variation, load variation, reflow drift, and 10 years aging).
.
External dimensions
(Unit:mm)
Footprint (Recommended)
(Unit:mm)
#4
#3
#3
#4
1.1
1.4
5.0
±0.2
2PC924A
#1
2.6
E 125.000H
#2
1.8
7.0
±0.2
#2
5.08
Pin map
Pin
Connection
1
OE
2
GND
3
OUT
4
Vcc
1.2
±0.2
3.9
#1
5.08
5.08
54
