PLC-116-M-2-B-C datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Optical fiber> PLC-116-M-2-B-C

PLC-116-M-2-B-C: DescriptionSplitter/Coupler, 1260nm Min, 1650nm Max, 1X16 Port, ST Connector; CategoryWireless rf/communication Optical fiber; File Size200KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric Compare View All

PLC-116-M-2-B-C Overview

Splitter/Coupler, 1260nm Min, 1650nm Max, 1X16 Port, ST Connector

PLC-116-M-2-B-C Parametric

Parameter Name	Attribute value
Objectid	1092276374
Reach Compliance Code	unknown
Connection Type	ST CONNECTOR
Fiber optic equipment types	SPLITTER/COUPLER
Fiber type	SMF-28
Maximum insertion loss	14.2 dB
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum operating wavelength	1650 nm
Minimum operating wavelength	1260 nm
Nominal operating wavelength	1455 nm
Port configuration	1X16
minimum return loss	55 dB

Preview

Download Datasheet

View All

Splitter

PLC Wideband Splitter

Parameter

Operating Wavelength Range

Insertion Loss

Uniformity

Return Loss

PDL

Maximum Power

Operating & Storage Temperature

Pigtailed

Package Dimensions

(in mm)

1RU 19” Rack Mount

LGX Box

1x4

≤ 7.5 dB

≤ 0.8 dB

1x8

≤ 11.0 dB

≤ 1.0 dB

≥ 55 dB

1 x 16

≤ 14.2 dB

≤ 1.5 dB

1 x 32

≤ 17.5 dB

≤ 2.0 dB

1260 - 1650 nm

≤ 0.2 dB

≤ 0.3 dB

300 mW

≤ 0.3 dB

≤ 0.4 dB

- 40° C ~ + 85° C

40 x 4 x 4

40 x 5 x 4

50 x 5 x 4

55 x 7 x 4

438.0 x 330.2 x 43.7

159 x 130 x 30

159 x 130 x 59 159 x 130 x 120 152.4 x 130 x 175

Note1: All values specified are without connectors.

Note2: Higher performance specifications upon request.

Note3: Fiber type Corning SMF-28e.

P L C

Port Number

104: 1 x 4

108: 1 x 8

116: 1 x 16

132: 1 x 32

Packaging

R: Pigtailed

M: 1RU 19 “ rack mount

X: LGX box

Fiber Length

Pigtail Style

(For R packaging)

1: 1 meter

A; Ribbon fiber

2: 2 meter

B: bare fiber

L: 900

µm

loose tube

R: 3 mm cable

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

www.lighteltech.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax

PLC-116-M-2-B-C Related Products

	PLC-116-M-2-B-C	PLC-132-M-2-R-B	PLC-132-R-2-A-5	PLC-108-R-2-A-A	PLC-132-M-1-R-6	PLC-104-X-1-L-B	PLC-132-R-2-B-C
Description	Splitter/Coupler, 1260nm Min, 1650nm Max, 1X16 Port, ST Connector	Splitter/Coupler, 1260nm Min, 1650nm Max, 1X32 Port, SC/UPC Connector	Splitter/Coupler, 1260nm Min, 1650nm Max, 1X32 Port, FC/SPC Connector	Splitter/Coupler, 1260nm Min, 1650nm Max, 1X8 Port, FC/UPC Connector	Splitter/Coupler, 1260nm Min, 1650nm Max, 1X32 Port, SC/SPC Connector	Splitter/Coupler, 1260nm Min, 1650nm Max, 1X4 Port, SC/UPC Connector	Splitter/Coupler, 1260nm Min, 1650nm Max, 1X32 Port, ST Connector
Reach Compliance Code	unknown	unknow	unknow	unknown	unknown	unknown	unknown
Connection Type	ST CONNECTOR	SC/UPC CONNECTOR	FC/SPC CONNECTOR	FC/UPC CONNECTOR	SC/SPC CONNECTOR	SC/UPC CONNECTOR	ST CONNECTOR
Fiber optic equipment types	SPLITTER/COUPLER	SPLITTER/COUPLER	SPLITTER/COUPLER	SPLITTER/COUPLER	SPLITTER/COUPLER	SPLITTER/COUPLER	SPLITTER/COUPLER
Fiber type	SMF-28	SMF-28	SMF-28	SMF-28	SMF-28	SMF-28	SMF-28
Maximum insertion loss	14.2 dB	17.5 dB	17.5 dB	11 dB	17.5 dB	7.5 dB	17.5 dB
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Maximum operating wavelength	1650 nm	1650 nm	1650 nm	1650 nm	1650 nm	1650 nm	1650 nm
Minimum operating wavelength	1260 nm	1260 nm	1260 nm	1260 nm	1260 nm	1260 nm	1260 nm
Nominal operating wavelength	1455 nm	1455 nm	1455 nm	1455 nm	1455 nm	1455 nm	1455 nm
Port configuration	1X16	1X32	1X32	1X8	1X32	1X4	1X32
minimum return loss	55 dB	55 dB	55 dB	55 dB	55 dB	55 dB	55 dB
Maker	-	Lightel Technologies Inc.	Lightel Technologies Inc.	Lightel Technologies Inc.	Lightel Technologies Inc.	-	-
