927.00 MHz SAW Filter
•
•
•
•
Designed to Band Pass in 927.00 MHz
Low-Loss, Coupled-Resonator Quartz Design
Simple External Impedance Matching
Ultra Miniature Ceramic QCC8C SMD Package
SF5012
Absolute Maximum Rating (Ta=25°C)
Parameter
Input Power Level
DC Voltage V
DC Between Any Two Pins
Operating Temperature Range
Storage Temperature Range
P
in
V
DC
Rating
10
12
-10 ~ +60
-40 ~ +85
Unit
dBm
V
°C
°C
T
A
T
stg
Electronic Characteristics
Parameter
Nominal Frequency (at 25°C)
(Center frequency between 3dB point)
Insertion Loss Attenuation
3dB Passband
Passband Ripple (within
±1.0
MHz)
Absolute Attenuation
DC … 887.00 MHz
987.00 … 1127.0 MHz
Frequency Aging
Absolute Value during the First Year
|f
A
|
-
-
Sym
f
C
Minimum
NS
-
-
-
Typical
927.00
3.5
±3.5
1.0
Maximum
NS
5.5
±5.0
±1.5
Unit
MHz
dB
MHz
dB
IL
BW
3
∆α
α
rel
45
40
-
1.0
-
50
45
-
-
50//10
-
-
10
-
-
dB
dB
ppm/yr
MΩ
Ω//pF
DC Insulation Resistance Between any Two Pins
Input / Output Impendance (nominal)
NS = Not Specified
Notes:
1.
The frequency
f
C
is defined as the midpoint between the 3dB
frequencies.
Unless noted otherwise, all measurements are made with the filter
installed in the specified test fixture that is connected to a 50Ω test
system with VSWR
≤
1.2:1. The test fixture L and C are adjusted
for minimum insertion loss at the filter center frequency,
f
C
. Note
that insertion loss, bandwidth, and passband shape are dependent
on the impedance matching component values and quality.
Unless noted otherwise, specifications apply over the entire
specified operating temperature range.
4.
2.
The specifications of this device are based on the test circuit
shown above and subject to change or obsolescence without
notice.
All equipment designs utilizing this product must be approved by
the appropriate government agency prior to manufacture or sale.
Our liability is only assumed for the Surface Acoustic Wave (SAW)
component(s) per se, not for applications, processes and circuits
implemented within components or assemblies.
For questions on technology, prices and delivery please contact
our sales offices or e-mail sales@vanlong.com.
5.
6.
3.
7.
Phone: +86 10 6301 4184
Fax: +86 10 6301 9167
Email: sales@vanlong.com
Web: http://www.vanlong.com
SF5012
©
August 2003 by Vanlong Technology Co., Ltd.
