RF-12
TM
ACR-22 SERIES
ACR–22–04–G–00.25–T–S1–P–2
IP68 SEALED 22 mm PANEL ASSEMBLY
SPECIFICATIONS
For complete specifications see
www.samtec.com?ACR-22
Terminal Material:
Brass
Contact Material:
Brass/BeCu
Housing:
–P: Thermoplastic
–M: Zinc Alloy
RoHS Compliant:
Yes
CURRENT RATING
CCC per
LEAD
PINS
PIN
STYLE POWERED
(70°C
ambient)
–01
30
2.0A
–02
20
2.3A
–03
8
8.3A
4
(plus 16
–05
signal pins
2.8A
powered
@ 1.4A)
For general reference only.
See www.samtec.com?ACR-22
for complete test data or contact
AccliMate@samtec.com for
AccliMate
applications requiring higher
current carrying capacity.
Mates with:
ACP-22
Bayonet lock
THINK OUTSIDE THE CATALOG
• Easy sealed
cable
solutions
• Build a
standard
or flexible
custom
online
• Calculate
performance,
current rating, voltage drop
• Live chat with AccliMate
™
engineers for
custom options
• Variety of shells, pin sizes, signal, power,
I/O interfaces
• Assembly and field kits available
• samtec.com/solutionator/sealedio
RF terminals
or sockets
Variety of
end 2 options
ACR
22
–01
LEAD
STYLE
PLATING
ALSO
AVAILABLE
• Field Termination Kit (ACRK)
• For complete specifications
on field termination kit see
www.samtec.com?ACR-22
• Dust Caps:
DCA-ACR-22-M-X (Metal)
DCA-ACR-22-P-X (Plastic)
• Visit www.samtec.com for
a complete list of sealed
systems
Call Samtec.
–05
= 1,5 mm DIA (4)
terminals or sockets
(16 AWG)
+ 1,0 mm DIA (16)
terminals or sockets
(24 AWG)
= 1,0 mm DIA (30)
terminals or sockets
(24 AWG)
–G
= 10µ" (0,25 µm) Gold over
50µ" (1,27 µm) Ni on contact
–02
(1,0) .040
DIA (30)
–H
= 30µ" (0,76 µm) Gold over
50µ" (1,27 µm) Ni on contact
RF (4)
= 1,0 mm DIA (20)
terminals or sockets
(24 AWG)
–06
= 1,0 mm DIA (12)
terminals or sockets
(24 AWG)
+ RF (4)
terminals or sockets
(RG 316)
–03
= 1,5 mm DIA (8)
terminals or sockets
(16 AWG)
–04
= RF (6)
terminals or sockets
(RG 316)
–01
(1,0) .040
DIA (12)
PANEL
OPENING
(12,25)
.482
–06
(1,0) .040
DIA (20)
(1,5) .060
DIA (8)
RF (6)
(1,5) .060
DIA (4)
(27,50)
1.08
DIA
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(1,0) .040
DIA (16)
–02
–03
–04
–05
WWW.SAMTEC.COM
ACR–22–05–G–00.25–S–S1–M–3
ACR–22–03–G–00.25–S–S1–P–1
Choice of terminal
or socket and
diameter combinations
Tested to IP68
for dust & water
Choice of
four keying
options
LENGTH
END 1
OPTION
END 2
OPTION
HOUSING
MATERIAL
KEYING
OPTIONS
–“XX.XX”
= Length in meters
(00.25 m min. to 50 m max.)
Contact Samtec for
other lengths
LEAD
MATES
-S1 END 2
STYLE
WITH -S1
–01
MMSD (24 AWG)
IPL1
–02
MPSS (16 AWG)
MPT
–03
6 x SMA (RG 316)
SMA
–04
–05
–06
1 x MPSS (16 AWG)
1 x MMSD (24 AWG)
1 x MMSD (24 AWG)
4 x SMA (RG 316)
MPT
IPL1
IPL1
SMA
–T
= Terminal
–S1
= Connector determined by lead style.
(Specify LEAD STYLE from chart)
–P
= Plastic
–S
= Socket
–BC
= Blunt Cut
–M
= Metal
–1
= Orange
–2
= Green
–3
= Blue
–4
= Yellow
KEYING OPTIONS
–04 END 2 (SMA)
135°
Overall Length = (XX.XX) ± 2%
–1
45°
–2
315°
(30,00)
1.181
225°
END 1
–01 END 2 (MMSD)
–03 END 2 (MPSS)
–3
–4
WWW.SAMTEC.COM
