P0102BL
0.25A SCRs
MAIN FEATURES:
Symbol
I
T(RMS)
V
DRM
/V
RRM
I
GT
Value
0.25
200
200
Unit
A
V
µA
A
G
G
K
A
DESCRIPTION
Thanks to highly sensitive triggering levels, the
PO102BL SCR is suitable for all applications
where the available gate current is limited such as
stand-by mode power supplies, smoke and alarm
detectors...
Available in SOT-23, it provides optimized space
saving on high density printed circuit boards.
SOT-23
K
ABSOLUTE RATINGS
(limiting values)
Symbol
I
T(RMS)
I
T(AV)
I
TSM
Parameter
RMS on-state current (180° conduction angle)
Average on-state current (180° conduction angle)
Non repetitive surge peak on-state
current
I
²
t Value for fusing
Critical rate of rise of on-state current
I
G
= 2 x I
GT
, tr
≤
100ns
Peak gate current
Average gate power dissipation
Storage junction temperature range
Operating junction temperature range
tp = 8.3 ms
Tj = 25°C
tp = 10 ms
tp = 10 ms
F = 60 Hz
tp = 20 µs
Tj = 25°C
Tj = 125°C
Tj = 125°C
Tj = 125°C
6
0.18
50
0.5
0.02
- 40 to + 150
- 40 to + 125
A
2
S
A/µs
A
W
°C
Tamb = 30°C
Tamb = 30°C
Value
0.25
0.17
7
Unit
A
A
A
I
²
t
dI/dt
I
GM
P
G(AV)
T
stg
Tj
资料提供：可控硅在线 ½½½½：／／½½½．½½½．½½½．½½
1/5
www.kersemi.com
P0102BL
ELECTRICAL CHARACTERISTICS
(Tj = 25°C, unless otherwise specified)
Symbol
I
GT
V
GT
V
GD
V
RG
I
H
I
L
dV/dt
V
TM
V
t0
R
d
I
DRM
I
RRM
V
D
= 12 V
V
D
= V
DRM
I
RG
= 10 µA
I
T
= 50 mA
I
G
= 1 mA
I
TM
= 0.4 A
R
GK
= 1kΩ
R
GK
= 1kΩ
R
GK
= 1kΩ
Tj = 125°C
Tj = 25°C
Tj = 125°C
Tj = 125°C
Tj = 25°C
Tj = 125°C
MAX.
tp = 380 µs
R
L
= 140
Ω
R
L
= 3.3 kΩ
R
GK
= 1 kΩ
Tj = 125°C
Test Conditions
MAX.
MAX.
MIN.
MIN.
MAX.
MAX.
MIN.
MAX.
MAX.
MAX.
P0102BL
200
0.8
0.1
8
6
7
200
1.7
1.0
1000
1
100
µA
Unit
µA
V
V
V
mA
mA
V/µs
V
V
mΩ
V
D
= 67 % V
DRM
Threshold voltage
Dynamic resistance
V
DRM
= V
RRM
THERMAL RESISTANCES
Symbol
R
th(j-a)
Parameter
Junction to ambient (mounted on FR4 with recommended pad layout)
Value
400
Unit
°C/W
PRODUCT SELECTOR
Part Number
P0102BL
Voltage
200 V
Sensitivity
200 µA
Package
SOT-23
ORDERING INFORMATION
P 01 02 B L
SENSITIVE
SCR
SERIES
CURRENT: 0.25A
SENSITIVITY:
02: 200µA
VOLTAGE:
B: 200V
Blank
5AA4
PACKING MODE:
Tape & Reel
PACKAGE:
L: SOT-23
OTHER INFORMATION
Part Number
P0102BL
Marking
P2B
Weight
0.01 g
Base quantity
3000
Packing mode
Tape & reel
2/5
