CC6F-T1AF
DIMENSIONS
Package:
Filter applications
Inverted Mesa AT Crystal 70 MHz – 200 MHz
Recommended Solder Pad:
3,5
0,8
0,8
1,2
1,5
1,2
2,2
100% leadfree, RoHS - compliant
max. 0,80
All dimensions in mm typical
Miniature SMT ceramic package
height 0.8 mm
Fundamental mode up to 200MHz
Inverted Mesa Technology
Ind. and Ext. temperature ranges
High stability and low aging
High shock and vibration resistance
Hermetically sealed
Ultra low MSl
Excellent solderability
Swiss made quality
Customer specification on request
DESCRIPTION:
This quartz Crystal in SMD ceramic package has been specially designed
with Micro Crystal photolitographic process for surface mount using
infrared, vapor phase or epoxy technics
APPlICATIONS:
- Filters
The crystals are supplied in trays (208 crystals per tray).
For pick-and-place equipment, the parts are available in 12mm tapes:
7” with 1’000 crystals
7” with 3’000 crystals
ElECTRICAl CHARACTERISTICS
AT 25
o
C:
Frequency Range
Load capacitance
Frequency tolerance at +25°C
Frequency versus temperature
TB: –40 to + 85°C
TC: –55 to + 125°C
Drive level typ/max
Insulation resistance min.
Aging first year max.
Spurious attenuation
Frequency spurius range
Frequency [ MHz ]
Series resistance typ./max.
Motional capacitance typ.
Static capacitance typ.
1)
2)
3)
F
l
C
L
ΔF/F
ΔF/F
0
P
R
i
ΔF/F
70–200
10.0 /
∞
± 20
± 20
± 50
100/250
500
+/-3
<-15
≤1
2,5
MHz
pF
ppm
ppm
µW
MΩ
ppm
dB
MHz
F
l
R
S
C
1
C
0
124
35 / 45
3
2.4
155.520
35 / 45
3
2.9
MHz
Ω
fF
pF
1) Other load capacitances on request.
2) Tighter and wider frequency tolerances on request.
3) Values for other frequencies consult factory.
4) Other parameters on request
STANDARD FREQUENCIES:
70
Frequency
MHz
124.782
Other frequencies from
70 MHz up to 200 MHz on request
ENVIRONMENTAl
CHARACTERISTICS:
Storage temp. range
TB Operating temperature range
TC Extended oper. temp. range
Shock resistance
Vibration resistance
Conditions
–55 to +125°C
–40 to +85°C
–55 to +125°C
5000 g, 0.3 ms, ½ sine
20 g / 10–2000 Hz
TERMINATIONS AND
PROCESSING:
Type
CC6F-T1AF
Termination
For SMD mounting
Au plated pads
Processing
Reflow soldering
+260°C / 20 s max.
PRODUCT DESCRIPTION AND
ORDERING INFORMATION:
CC6F–T1AF
155.520 MHz
∞
Frequency F
L
C
L
Load Capacitance
10.0 pF
∞
pF
Frequency tolerance
+/- 20 ppm
+/- 50 ppm
pF +/-50ppm
TB
QI
Temperature Range
TB
= - 40 to +85°C (Standard)
TC
= - 55 to +125°C
Optional:
if not defined,
‚Standard‘ will apply
Qualification
QI
= Industrial (Standard)
QS
= Custom Specification
A unique part number will be generated for each product specification, i.e:
20xxxx-MG01
1‘000 pcs
(
in 12mm tape on 7“ reel)
20xxxx-MG02
20xxxx-EA00
4
2‘000 pcs
xxx pcs
Please contact us.
(
in 12mm tape on 7“ reel)
(
in plastic tray)
All specifications subject to change without notice.
Micro Crystal AG
Mühlestrasse 14
CH-2540 Grenchen
Switzerland
Tel.
+41 32 655 82 82
Fax
+41 32 655 82 83
sales@microcrystal.com
www.microcrystal.com
Version 1.0/02.2015
