DMT10-2-1211
DMT
LONG RANGE DISTANCE SENSORS
Online data sheet
DMT10-2-1211 | DMT
LONG RANGE DISTANCE SENSORS
A
B
C
D
E
F
H
I
J
K
L
M
N
O
P
Q
R
S
T
Ordering information
Type
DMT10-2-1211
Other models and accessories
www.sick.com/DMT
Part no.
1027604
Detailed technical data
Performance
Measuring range
0.5 m ... 155 m, 90 % remission
0.5 m ... 65 m, 18 % remission
0.5 m ... 40 m, 6 % remission
≤ 1 mm
7 mm
1)
2)
10 mm
3)
2)
Resolution
Repeatability
Accuracy
Response time
Cycle time
Average depth
Output time
Aperture delay time
Light source
Laser class
Typ. light spot size (distance)
Note
Special characteristic
1)
2)
3)
4)
5)
6)
7)
± 10 mm
4)
5)
1 ms ... 4,000 ms
6)
1,024 per sec.
1/16/64/256/1,024
1 ms ... 4,000 ms
7)
≥ 1 s
7)
Laser, infrared
1 (EN 60825-1:Nov.2001, IEC 60825-1:ÄM2:2001)
20 mm (+ 5 x distance in m)
Mechanical aperture
Mechanical aperture
Dependent on distance and remission, 7 mm, at 6% ... 90% remission from 0.5 m ... 65 m, at 6% ... 18% remission from 0.5 m ... 40 m, at 6% remission from
0.5 m ... 15 m.
Environmental conditions constant, min. warm-up time 30 min, average depth 1,024, statistical error 1 σ.
Dependent on distance and remission, 10 mm, at 6% ... 90% remission from 60 m ... 155 m, at 6% ... 18% remission from 40 m ... 65 m, at 6% remission from
15 m ... 40 m.
23 °C air temperature, 977 hPa, min. warm-up time 30 min.
When operating in ambient temperatures between +40 °C ... +55 °C the accuracy can decrease by factor 2.5.
Dependent on averaging method, averaging depth, timeout, baud rate, data output, output format, and delay time.
Dependent on averaging method, averaging depth, timeout, baud rate, data output, and output format.
Interfaces
Data interface
Interface for parametrization
PROFIBUS DP
RS-232
2
DISTANCE SENSORS | SICK
Online data sheet | 2016-03-17 13:18:11
Subject to change without notice
LONG RANGE DISTANCE SENSORS
Mechanics/electronics
Supply voltage V
s
Ripple
Power consumption
Initialization time
Connection type
Weight
Output current I
A
1)
2)
DMT10-2-1211 | DMT
DC 18 V ... 30 V, limit values
< 5 V
pp
1)
≤ 6 W
2)
6 s
1 x terminal connection, 1 x Sub D, 9-pin
Approx. 1,200 g
100 mA
May not fall short of or exceed V
S
tolerances.
Without load.
Ambient data
Enclosure rating
Protection class
Electromagnetic compatibility (EMC)
Ambient temperature
IP 65
III
1)
EN 55011:1998 Kl. B, Gr.1
EN 61000-6-2
Operation: –10 °C ... +55 °C
Operation with cooling case: –10 °C ... +75 °C
Storage: –25 °C ... +70 °C
Typ. 0.6 mm/K
2)
Typ. 0.3 mm/K
3)
Shock: (IEC 60068-2-27, –2-29)
Sine: (IEC 60068-2-6)
Temperature drift
Mechanical load
1)
2)
3)
Reference voltage DC 50 V PELV-voltage (EN 50178)
-10° C ... 0° C, +40 °C ... +55 °C.
0 °C ... +40 °C.
2016-03-17 13:18:11 | Online data sheet
Subject to change without notice
DISTANCE SENSORS | SICK
3
DMT10-2-1211 | DMT
LONG RANGE DISTANCE SENSORS
99.5
(3.92)
1.5
(0.06)
H
I
J
K
L
M
N
O
P
Q
R
S
T
(0.14)
M6
42.5
(1.67)
102.5
(4.04)
(0.85)
① Dust
protection tube
② Laser
pointer pilot light
③ Alignment
sight
④ Function
indicator
⑤ Zero
level
⑥ Mounting
hole M6 threaded - 6 mm deep
⑦ Connector
cover
⑧ PG9
⑨ Sub-D,
9-pin
⑩ Sub-D,
9-pin
Connection type
DMTxxx-2 RS-232/PROFIBUS Connector
5
1
6
9
① NReset
⑤ M
⑥ NC =
normally closed
⑨ NC =
normally closed
4
DISTANCE SENSORS | SICK
(0.49)
12.5
3.5
96
(3.78)
6
(2.17)
55
A
B
C
D
E
F
Dimensional drawing
(Dimensions in mm (inch))
DMT10-2-x2xx DML40-2-x2xx
6
1
95
(3.74)
15.5
(0.61)
213.5
(8.41)
56.5
5
(2.22)
23 4
139
(5.47)
18
(0.71)
70
(2.76)
M
8
9
ß
7
21.5
Online data sheet | 2016-03-17 13:18:11
Subject to change without notice
LONG RANGE DISTANCE SENSORS
DMTxxx-2 RS-232/PROFIBUS Socket, Sub-D, 9-pin
DMT10-2-1211 | DMT
1
5
9
6
① NC =
normally closed
⑤ M
⑥ L+
⑨ NC =
normally closed
DMTxxx-2 RS-232/PROFIBUS PG9
12
1
2
① Pin
1
② Pin
2
Connection diagram
Connection diagram DMxxx-2-x21x RS-232
RS-232
1
2
3
5
RESET
RxD
TxD
GND
Connection type DMxxx-2 RS-232/PROFIBUS, socket
3 B
4 RTS
5 GND
6 +5 V
8 A
DMTxxx-2 RS-232/PROFIBUS PG9
1
2
L+
M
2016-03-17 13:18:11 | Online data sheet
Subject to change without notice
DISTANCE SENSORS | SICK
5
