Power Splitter/Combiner
6 Way-0°
Operating Temperature
Storage Temperature
Power Input (as a splitter
1
)
Internal Dissipation
DC Current
High Power, DC Pass
ZN6PD-272HP+
ZN6PD-272HPX-S+
▲
ZN6PD-272HP-S+
50Ω
Up to 100W
650 to 2750 MHz
Generic photo used for illustration purposes only
Maximum Ratings
-55°C to 60°C
-55°C to 100°C
100W max.
3.0W max.
Features
• power handling up to 100W
• wideband, 650 to 2750 MHz
• low insertion loss, 0.9 dB typ.
• good isolation, 25 dB typ.
• rugged shielded case
CASE STYLE: AW257-2
Connectors
SMA
SMA
N-TYPE
N-TYPE
Model
ZN6PD-272HP-S+
ZN6PD-272HPX-S+
▲
ZN6PD-272HP-N+
ZN6PD-272HPX-N+
▲
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
1.2A (200mA for each port)
Permanent damage may occur if any of these limits are exceeded.
Applications
• WiMax
• LTE
• WCDMA
Coaxial Connections
SUM PORT
PORT 1,2,3,4,5,6,7,8
S
1,2,3,4,5,6
Outline Drawing
MOUNTING INFORMATION FOR
MODELS WITHOUT HEATSINK
Electrical Specifications at 25°C
Parameter
Frequency Range
Insertion Loss
(above theoretical 7.8 dB)
Isolation
Phase Unbalance
Amplitude Unbalance
VSWR (Port S)
VSWR (Port 1-8)
Power Handling
As Splitter
As Combiner
2
1
Frequency (MHz)
650-2750
700-2700
650-2750
700-2700
650-2750
650-2750
700-2700
650-2750
700-2700
650-2750
650-2750
650-2750
Min.
650
—
—
18
20
—
—
—
—
—
—
—
—
Typ.
1.0
0.9
23
25
4
0.4
0.3
1.35
1.30
1.15
—
—
Max.
2750
1.6
1.4
—
—
10
0.7
0.6
1.55
1.5
1.30
100
3.0
Unit
MHz
dB
dB
Degree
dB
:1
:1
Watt
1. All outputs must terminate 50 ohm (VSWR 1.5:1 or better)
2. As a combiner of non-coherent signals, max. power per port is 3.0 watt power rating divided by number of ports.
▲
Heat sink and fan not included. Alternative heat sinking and heat removal must be provided by the user to limit maximum base-plate tem-
perature to 60°C, in order to ensure proper performance. For reference, this requires thermal resistance of user’s external heat sink to be
1.2°C/W max.
Typical Performance Data
Outline Dimensions (
inch
)
mm
A
8.06
204.72
H
.890
22.61
B
3.25
82.55
C
2.38
60.45
D
E
.125 7.560
3.18 192.02
F
2.625
66.68
G
.144
3.66
Frequency
(MHz)
S-1
650
700
850
1000
1150
1300
1450
1600
1800
1900
2000
2200
2400
2500
2600
2750
8.31
8.22
8.29
8.30
8.34
8.36
8.39
8.46
8.55
8.57
8.57
8.65
8.61
8.62
8.65
8.72
Total Loss
1
(dB)
S-3
8.21
8.13
8.20
8.21
8.25
8.28
8.32
8.40
8.49
8.51
8.50
8.59
8.56
8.60
8.66
8.77
Amplitude
Unbalance
(dB)
S-5
7.93
7.85
7.94
7.96
7.99
8.03
8.08
8.16
8.26
8.28
8.28
8.36
8.40
8.46
8.54
8.70
0.38
0.37
0.35
0.35
0.35
0.33
0.31
0.29
0.29
0.28
0.28
0.28
0.20
0.16
0.16
0.26
Isolation
(dB)
Adjacent Opposite
22.50
25.54
25.88
43.12
27.41
28.87
43.55
27.59
23.65
24.11
27.79
24.43
33.75
35.06
28.92
29.56
22.35
25.14
24.86
39.30
28.62
29.24
42.17
26.48
22.60
22.93
26.20
24.99
31.00
33.65
28.30
26.67
Phase
Unbal.
(deg.)
0.62
0.68
0.96
1.00
1.19
1.31
1.40
1.48
1.70
1.84
1.82
1.61
1.39
1.44
1.39
1.21
VSWR
S
VSWR
OUTPUTS
J
K
.44
7.06
11.18 179.32
L
M
N
wt
.88
3.13
.75 grams*
1240
22.35 79.50
19.05
*850 grams without heatsink
Electrical Schematic
(DC THROUGH)
PORT 1 RF+DC
PORT S
RF+DC
PORT N RF+DC
PORT 2 RF+DC
1.39
1.12
1.24
1.17
1.21
1.11
1.14
1.23
1.26
1.25
1.22
1.26
1.05
1.06
1.13
1.26
1.08
1.06
1.10
1.11
1.06
1.03
1.10
1.12
1.12
1.09
1.09
1.14
1.04
1.03
1.04
1.01
1. Total Loss = Insertion Loss + 7.8dB theoretical splitter loss.
9.5
TOTAL LOSS (dB)
9.0
8.5
ZN6PD-272HP+
TOTAL LOSS
52
ZN6PD-272HP+
ISOLATION
1--2
2--3
3--4
4--5
VSWR
1.4
1.3
1.2
1.1
ZN6PD-272HP+
VSWR
ISOLATION (dB)
S-1
S-3
S-5
VSWR S
VSWR OUT
44
36
28
20
650
1175
1700
2225
FREQUENCY (MHz)
2750
8.0
7.5
650
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
1175
1700
2225
FREQUENCY (MHz)
2750
1.0
650
1175
1700
2225
FREQUENCY (MHz)
2750
www.minicircuits.com
P.O. Box 350166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
REV. A
M170684
ZN6PD-272HP+
ED-17251/1
JC/CP/AM
200427
Page 2 of 2
