DATA SHEET
CITILED COB Series
Standard Type
Ra90min. Model
CLU058-1825C4
Introduction
Performance Characteristics
Mechanical Dimensions
Characteristic Curves
Reliability
Packing Specification
Precaution
P 2
P 3
P 5
P 6
P 9
P 10
P 11
1
Ref.CE-P3712 05/16
Product Nomenclature
CLU058 - 18 25 C4 - 27 3 H5 K2
[1]
[1]
[2]
[3]
[4]
[5]
Product shape
Die count in series
Die count in parallel
Nominal CCT
CRI (Ra)
[2]
[3]
[4]
CLU058
18
25
2700K
Min.90
[5]
1. Introduction
1-1. Product Description
CITIZEN ELECTRONICS is the first COB manufacture. Our advanced knowledge and packaging technology for many
years has excellent reliability and high quality of our products. CITILED COB Series covers a wide range of luminous flux
from a 10W incandescent bulb to a 500W mercury lamp in general lighting sources. The element arrangement of LED
package is capable of utilizing light more effectively and higher performance.
The new version of CITILED COB Series succeed to reduce the thermal resistance significantly. New version creates
more options to match luminaire's products design (ex. High performance , Cost effective , Higher lumen density ,
Increased allowable max. If). The outline and LES size is same since version 1. 3-step MacAdam ellipse color definition at
Tj=85
℃
is available.
1-2. Features
2
Ref.CE-P3712 05/16
2. Performance Characteristics
2-1. Electro Optical Characteristics
( Tj=85C )
Nominal
CCT
CRI
Ra
Min.
CLU058-1825C4-273H5K2
CLU058-1825C4-303H5K2
CLU058-1825C4-353H5K2
CLU058-1825C4-403H5K2
CLU058-1825C4-573H5K2
Notes :
1. Citizen Electronics maintains forward voltage +/-3%, luminous flux +/-10%,Ra and R9 +/-1.
*Values of Luminous flux at Tc=25C are provided as reference only.
2700K
3000K
3500K
4000K
5700K
90
90
90
90
90
R9
Min.
50
50
50
50
50
Luminous flux
( lm )
Efficacy Forward
( lm/W ) Current
Tc=25C*
( mA )
Typ.
Typ.
14,962
15,638
15,939
16,107
16,993
118
123
125
127
134
2,250
2,250
2,250
2,250
2,250
Voltage
( V)
Min.
47.8
47.8
47.8
47.8
47.8
Typ.
52.0
52.0
52.0
52.0
52.0
Max.
56.2
56.2
56.2
56.2
56.2
Thermal
Resistance
Rj-c
(
C/W )
0.14
0.14
0.14
0.14
0.14
Product code
T½=85C
Min.
Typ.
12,100 13,750
12,647 14,372
12,890 14,648
13,026 14,803
13,742 15,617
2-2. Absolute Maximum Ratings
Parameter
Input Power (W)
Forward Current (mA)
Reverse Current (mA)
Operating Temperature (C)
Storage Temperature (C)
Case Temperature (C)
Junction Temperature (C)
Symbol
Pi
If
Ir
Top
Tst
Tc
Tj
Rating
364.6
5750
1
-40 ~ +100
-40 ~ +100
105
140
*2
*3
*1
*1
*1. Input power and forward current are the values when the LED is used within the range of the derating
curve in this data sheet.
*2. Refer to 3. Outline drawing for Tc measurement point.
*3. D.C. Current : Tj = Tc + Rj-c
×
Pi
3
Ref.CE-P3712 05/16
2-3. Chromaticity Characteristics
( Rated current, Tj=85C )
Oval parameter
Color Region
Nominal
CCT
2700K
3000K
3-step MacAdam ellipse
3500K
4000K
5700K
Center Point
( x, y )
( 0.4577 , 0.4098 )
( 0.4339 , 0.4032 )
( 0.4078 , 0.3929 )
( 0.3818 , 0.3796 )
( 0.3287 , 0.3417 )
Major Axis
a
0.00774
0.00834
0.00951
0.00939
0.00760
Minor Axis
b
0.00411
0.00408
0.00417
0.00402
0.00296
Ellipse
Rotation Angle
θ
57.28
53.17
52.97
54.00
59.46
* Color region stay within MacAdam 3-step ellipse from the chromaticity center.
* The chromaticity center refers to ANSI C78.377:2011.
Please refer to ANSI C78. 377 for the chromaticity center.
* θ is the angle between the major axis of the ellipse and the x-axis, and a and b are the major and minor semi-axes of an ellipse.
(Ref. IEC 60081:1997 AnnexD)
0.45
x-y chart CIE1931
3,000K
3,500K
2,700K
0.40
4,000K
Black
Body
Locus
y
5,700K
0.35
3-step
0.30
0.30
0.35
0.40
x
0.45
0.50
Note : Citizen Electronics maintains chromaticity ( x, y ) +/-0.005
4
Ref.CE-P3712 05/16
3. Mechanical Dimensions
・
Internal Circuit
Marking 1 :
Serial No.
Marking 2 : H 18 25 ** **
CRI
CCT
Dies count in parallel
Dies count in series
CLU058
Protection
device
Anode
LED device
Cathode
18 s 25 p
5
Ref.CE-P3712 05/16
