Shielded Power Inductors – SER1390
• Exceptionally high current carrying capability
• Low DC resistance
Core material
Ferrite
Terminations
RoHS compliant matte tin over nickel over phos bronze.
Other terminations available at additional cost.
Weight
4.0 – 4.8 g
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
300 per 13″ reel; Plastic tape: 24 mm wide, 0.5 mm thick,
20 mm pocket spacing, 9.6 mm pocket depth
PCB washing
Tested with pure water or alcohol only. For other solvents,
see Doc787_PCB_Washing.pdf
Inductance
2
±20% (µH)
10
15
22
33
47
DCR (mOhm)
3
typ
max
13.7
13.7
21.0
21.0
21.0
15.0
15.0
23.1
23.1
23.1
SRF typ
4
(MHz)
26.9
24.3
20.3
15.7
13.2
Isat
(A)
5
20% drop
12.56
8.04
6.80
4.40
3.00
Irms
(A)
6
20°C rise 40°C rise
6.4
6.4
5.7
5.7
5.7
9.2
9.2
7.7
7.7
7.7
Part number
1
SER1390-103ML_
SER1390-153ML_
SER1390-223ML_
SER1390-333ML_
SER1390-473ML_
10% drop
11.32
7.20
6.08
3.80
2.60
30% drop
13.16
8.60
7.36
4.76
3.20
1. When ordering, please specify
termination
and
packaging
codes:
SER1390-473MLD
Termination: L
= RoHS compliant matte-tin over nickel over phos bronze.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: D
= 13″ machine-ready reel. EIA-481 embossed plastic tape (300 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use code letter D instead.
2. Inductance measured at 100 kHz, 0.1 Vrms, 0 Adc on an Agilent/HP 4284A or equivalent.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using an Agilent/HP 4395A network analyzer and an Agilent/HP 16193A test fixture.
5. DC current at which the inductance drops the specified amount from its value without current.
6. Current that causes the specified temperature rise from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 1096-1
Revised 09/16/13
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 1096 -2
Shielded Power Inductors – SER1390 Series
L vs Current
100
47 µH
33 µH
L vs Frequency
100
47 µH
33 µH
22 µH
Inductance (µH)
Inductance (µH)
22 µH
15 µH
10
10 µH
10
15 µH
10 µH
1
0.1
1
10
100
1
0.1
1
10
100
Current (A)
Frequency (MHz)
0.531 max
13,5
Current Derating
120
110
1
2
3
Terminal 3 is for
mounting stability only.
SER1390-XXX
Percent of rated current
100
90
80
70
60
50
40
20
10
0
0.531 max
13,5
Isat
Irms
-40
-20
0
20
25°C
30
0.354
max
9,0
XXXXY
0.006 / 0,152
40
60
80
100
120 140
Ambient temperature (°C)
0.110 ±0.008
2,8 ±0,2
0.173 ±0.008
4,4 ±0,2
0.110 ±0.008
2,8 ±0,2
0.091 ±0.008
2,3 ±0,2
0.071 ±0.004
1,80 ±0,1
0.370 ±0.008
9,40 ±0,2
0.063 ±0.008
1,60 ±0,2
0.089
2,26
0.121
3,07
0.163
4,14
0.121
3,07
2
1
0.366
9,3
0.089
2,26
Recommended
Land Pattern
3
0.109
2,77
Dimensions are in
inches
mm
Revised 09/16/13
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 1096-2
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
