Accessories
Contact blocks and lamp blocks with holder for front mounting
Max. number
of blocks
in holder
Included
blocks
Catalog No.
Ref. Code
For non-illuminated operators
3
3
3
3
3
3
3
3
3
3
3
3
3
3
1 NC
1 NO
2 NC
2 NO
3 NC
3 NO
1 NO + 1 NC
1 NO + 2 NC
2 NO + 1 NC
1 NC + 1 LB
1 NO + 1 LB
1 NO + 1 NC + 1 LB
2 NC + 1 LB
2 NO + 1 LB
MCBH-01
MCBH-10
MCBH-02
MCBH-20
MCBH-03
MCBH-30
MCBH-11
MCBH-12
MCBH-21
MCBH-011
MCBH-101
MCBH-111
MCBH-021
MCBH-201
1SFA 611 605 R1110
1SFA 611 605 R1101
1SFA 611 605 R1120
1SFA 611 605 R1102
1SFA 611 605 R1130
1SFA 611 605 R1103
1SFA 611 605 R1111
1SFA 611 605 R1121
1SFA 611 605 R1112
1SFA 611 605 R1210
1SFA 611 605 R1201
1SFA 611 605 R1211
1SFA 611 605 R1220
1SFA 611 605 R1202
For illuminated operators
8
Single contact blocks for front mounting
Included
blocks
Catalog No.
Ref. Code
1 NO
1 NC
1 NO with gold plated contacts
1 NC with gold plated contacts
MCB-10
MCB-01
MCB-10G
MCB-01G
1SFA 611 610 R1001
1SFA 611 610 R1010
1SFA 611 610 R1101
1SFA 611 610 R1110
Double contact block for front mounting
To be used together with MCBH5-00 when contact blocks in position 4- and 5- are needed.
Also when using MCBH-00 together with selector switch and contact block in positioon 3- is needed
Included blocks
Catalog No.
Ref. Code
2 NO
2 NC
1 NO + 1 NC
MCB-20
MCB-02
MCB-11
1SFA 611 610 R1002
1SFA 611 610 R1020
1SFA 611 610 R1011
Single lamp blocks for front mounting, Ba 9s base
Description
Catalog No.
Ref. Code
For max. 2 W, 230 V AC and DC
filament bulb or LED
115 V AC supply voltage.
For 60 V filament bulb
max. 1.2 W
230 V AC supply voltage.
For 130 V filament bulb
max. 2 W
115 V AC and DC supply voltage
For 24 V LED
24 V AC and DC supply voltage.
With resistor. Intended for electronic
circuits. The resistor limits the making
current and protects against disturban-
ces in the electronic circuit
For 24 V filament bulb
MLB-1
1SFA 611 620 R1001
MLB-2
1SFA 611 620 R1002
MLB-3
MLB-4
1SFA 611 620 R1003
1SFA 611 620 R1004
MLB-5
1SFA 611 620 R1005
Holders
Description
Catalog No.
Ref. Code
Holders for front mounting
For three blocks
For five blocks
MCBH-00
MCBH5-00
1SFA 611 605 R1100
1SFA 611 601 R1100
Contact blocks and lamp blocks for rear mounting
See Page 8.43
8.22
1SXU 105 017 C0201
Discount schedule CA
Low Voltage Products & Systems
ABB Inc. • 888-385-1221 • www.abb-control.com
Accessories
Pi
lo
t
En
De
clo
vic
se
es
d
8
Contact blocks for rear mounting
Description
Catalog No.
Ref. Code
Contact block
1NO
1NC
MCB-10B
MCB-01B
1SFA 611 610 R2001
1SFA 611 610 R2010
Double contact block
2NO
2NC
1NO+1NC
MCB-20B
MCB-02B
MCB-11B
1SFA 611 610 R2002
1SFA 611 610 R2020
1SFA 611 610 R2011
Contact block with
gold plated contacts
1NO
1NC
MCB-10BG
MCB-01BG
1SFA 611 610 R2101
1SFA 611 610 R2110
Lamp blocks
For max. 2 W, 230 V AC and DC
filament bulb or LED
115 V AC supply voltage.
For 60 V filament bulb
max. 1.2 W
230 V AC supply voltage.
For 130 V filament bulb
max. 2 W
MLB-1B
1SFA 611 620 R2001
8
MLB-2B
1SFA 611 620 R2002
MLB-3B
1SFA 611 620 R2003
Protective sleeve
Description
Catalog No.
Ref. Code
To make a rear mounted lamp block
screen protected. IP20
5396 0543-1
5396 0543-1
Earthing terminal
Description
Catalog No.
Ref. Code
For plastic enclosure.
MA5-2005
1SFA 611 925 R3005
Spacer
Description
Catalog No.
Ref. Code
1 mm thick. Needed when legend plates
are not used in plastic enclosures.
Spacer (Packing unit 10 pieces)
Spacer for Modular emergency stop
pushbutton, page ??
(Packing unit 10 pieces)
SK 615 516-1
SK 615 516-1
KA1-8045
1SFA 616 920 R 8045
Blanking plug (22
mm
)
Description
Catalog No.
Ref. Code
Black plastic
SK 615 502-B
SK 615 502-B
Low Voltage Products & Systems
ABB Inc. • 888-385-1221 • www.abb-control.com
Discount schedule CA
8.45
1SXU 105 017 C0201
