PEL12T-4231G-S1024 datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> PEL12T-4231G-S1024

PEL12T-4231G-S1024: DescriptionROTARY OPTICAL POSITION ENCODER; CategoryLED optoelectronic/LED; File Size70KB，1 Pages; ManufacturerBourns; Websitehttp://www.bourns.com

Download Datasheet Parametric View All

PEL12T-4231G-S1024 Overview

ROTARY OPTICAL POSITION ENCODER

PEL12T-4231G-S1024 Parametric

Parameter Name	Attribute value
state	ACTIVE
Optoelectronic device type	ROTARY

Preview

Download Datasheet

View All

ENCODERS

ADVANCE NOTICE

Bourns® Model PEL12 Series Encoder

w/Illuminated Shaft

Riverside, California - TO BE RELEASED DECEMBER 6, 2010 - Bourns® Resistive Products Division proudly

announces the release of our Model PEL12 Series 12 mm Incremental Encoder with Illuminated Shaft and Switch

Option.

Model PEL12 Series Encoder consists of three discrete models:

• PEL12S – Single LED version

• PEL12D – Dual LED version with switch

• PEL12T – Triple LED version with switch

Model PEL12 Series Encoder features:

• Operating Temperature: -10 °C to +70 °C

• Rotational Life: 30,000 cycles

• 24 PPR resolution

• Detent option

•

Momentary push switch

Knurled and ﬂatted shaft styles

Variety of LED colors

RoHS Compliant*

The PEL12 Series Encoder with Illuminated Shaft can be used in applications such as audio-visual equipment,

consumer electronic appliances, portable electronics, environmental controls, communication equipment, and

instrument panels. Other applications include professional audio equipment such as portable mixers,

keyboards, guitar effects, and sound processors.

Samples and production quantities are now available. For your convenience, the data sheet is available on

the Bourns website at www.bourns.com under Contacting Encoders, and on the Pro Audio website at

www.bourns.com/proaudio under Pro Audio Products.

Features

■

Applications

Level control, tuning and timer settings in:

■

Audio-visual equipment

■

Consumer electric appliances

■

Musical instrumentation

■

Communication equipment

Compact design, long life and high reliability

Vertical and horizontal mount versions

Momentary switch (PEL12D & PEL12T)

Single (PEL12S),

dual (PEL12D) and

triple (PEL12T) LED design

Flatted and knurled shaft styles

RoHS compliant*

*RoHS Directive 2002/95/EC Jan 27, 2003 including Annex.
