Ceramic
High Pass Filter
1700 to 5000 MHz
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power Input*
-55°C to 100°C
-55°C to 100°C
7W max. at 25°C
EW!
N
HFCN-1320
Features
•
•
•
•
•
low cost
small size
7 sections
temperature stable
excellent power handling, 7W
CASE STYLE: FV1206
Model
HFCN-1320
HFCN-1320D
Price
$1.99
$2.49
Qty.
(10-49)
(10-49)
*Passband rating, derate linearly to 3W at 100°C ambient.
Applications
Pin Connections
RF IN
RF OUT
GROUND
** RF IN & RF OUT can be interchanged
1**
3**
2,4
• sub-harmonic rejection
• transmitters/receivers
• lab use
High Pass Filter Electrical Specifications
1
(T
AMB
=25°C)
MODEL
NO.
STOP BAND
(MHz)
Min.
(loss>40 dB)
HFCN-1320
910
(loss>20 dB)
1060
Outline Drawing
fco, MHz
Nom.
(loss 3 dB)
Typ.
1320
PASSBAND
(MHz)
(loss<1.3 dB)
Max.
1700-3800
(loss<2 dB)
Typ.
1400-5000
VSWR
Typ.
Stopband
20:1
POWER
INPUT
Frequency
(W)
(MHz)
1.5:1
1700-3700
7
1. For Applications requiring DC voltage to be applied to the Input or output, use HFCN-1320D (DC Resistance to
ground is 100 Mohms min.)
typical frequency response
ATTENUATION (dB)
schematic
RF IN
RF OUT
40dB
20dB
3dB
B
f co
FREQUENCY
f
1.3 dB
Typical Performance Data at 25°C
Frequency
(MHz)
1.00
500.00
920.00
1070.00
1250.00
1328.00
1500.00
1700.00
2000.00
3000.00
4000.00
5000.00
6000.00
7000.00
8000.00
Insertion Loss
(dB)
94.16
58.01
58.86
28.39
8.11
3.15
1.47
0.88
0.62
0.44
0.77
1.70
2.95
4.34
5.26
VSWR
(:1)
>20
>20
>20
>20
5.42
2.08
1.86
1.57
1.41
1.06
1.67
2.61
4.00
6.07
7.83
Outline Dimensions (
inch
)
mm
A
.126
3.20
H
.087
2.21
B
.063
1.60
J
.024
0.61
C
.037
0.94
K
.122
3.10
D
.020
0.51
L
.024
0.61
E
.032
0.81
M
.087
2.21
F
.009
0.23
N
.012
0.30
G
.169
4.29
P
wt
.071 grams
1.80
.020
Demo Board MCL P/N: TB-270
Suggested PCB Layout (PL-137)
HFCN-1320
INSERTION LOSS
100
90
INSERTION LOSS (dB)
80
70
50
40
30
20
10
0
0
1000
2000
3000
4000
5000
6000
7000
FREQUENCY (MHz)
1
0
1000
2000
10
VSWR
60
1000
10000
HFCN-1320
VSWR
100
3000
4000
5000
6000
7000
FREQUENCY (MHz)
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
ISO 9001 & ISO 14001
Certified
NO. OF
SECTIONS
7
R E V .C
M96263
EDR-6437/2
HFCN-1320
RVN/AD/CP
050113
