SHEET 1 OF 1
n
22.00
`
.10
[.866
`
.004
in]
n
22.00
`
.10
[.866
`
.004
in]
10.50
`
.10
[.413
`
.004
in]
RING ILLUMINATION
n
25.00
[.984 in]
n
18.00
[.709 in]
2.44
[.096 in]
.40
[.016 in]
RECOMMENDED PANEL CUTOUT
OPTIONAL PANEL CUTOUT
MAX. PANEL THICKNESS 12mm MAX. PANEL THICKNESS 12mm
n
13.80
1.64
[.064 in]
[.543 in]
A
LASER ENGRAVED
M10 MARKING
ACTUATOR COLOR:
STAINLESS STEEL
MACHINE FINISH
2.00
[.079 in]
2.44
[.096 in]
11.40
[.449 in]
ARIAL ROUNDED
MT BOLD FONT
SWITCH FUNCTION
1
3
(-)
2
4
(+)
1-2 ON
3-4 OFF
1-2 (OFF)
3-4 (ON)
POS. 1
POS. 2
DETAIL A
SCALE 2 : 1
BODY COLOR:
STAINLESS STEEL
MACHINE FINISH
DPST
CONTACT CONFIGURATION
10.30
`
.10
[.405
`
.004
in]
( ) = MOMENTARY
B
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
B
41.00
`
.50
2. GENERAL TOLERANCE: X.X = ± 0.4
[1.614
`
.020
in]
X.XX = ± 0.25
3. TERMINAL NOS. FOR REF. ONLY
4. FUNCTION: DPST
5. RATING: 2A @ 48VDC
6. ILLUMINATION VOLTAGE: 12V
7. CONTACT RESISTANCE: 50m MAX. @ 1A 12VDC
8. INSULATION RESISTANCE: 1,000M @ 500VDC
9. DIELECTRIC STRENGTH: 2,000VAC MIN. FOR 1 MINUTE
10. ELECTRICAL LIFE: 50,000 CYCLES
11. OPERATING TEMPERATURE: -20°C TO 55°C
12. INGRESS PROTECTION: IP65
13. DENOTES CRITICAL PARAMETER
13. 2002/95/EC (ROHS) COMPLIANT
14. ILLUMINATION COLOR: BLUE (FORWARD), BLUE (REVERSE)
15. HARDWARE INCLUDED (NOT SHOWN) HEX NUT AND O-RING
B
A
REV
21426
21357
PCR NO
BODY WAS 5MM SHORTER
RELEASE FOR PRODUCTION
DESCRIPTION
4/4/14
1/17/14
DATE
30.70
`
.50
[1.209
`
.020
in]
B
22.20
[.874 in]
M22x1.0
3
1
(+)
2
4
(+)
4
(-)
2
7.00
[.276 in]
13.60
[.535 in]
.50
[.020 in]
6 PLACES
2.80
[.110 in]
6 PLACES
6.00
[.236 in]
EBP
EBP
BY
TITLE
PV7F2Y0SS-344-M10
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
1/17/2014
EBP
52-PV7F2Y0SS344M10
B
