MANO 9600 9.6 MegaPixel Rolling Shutter CMOS Image Sensor

Preview

Download Datasheet

View All

NOIM1SM9600A,

NOIM2SM9600A

Advance Information

MANO 9600 9.6 MegaPixel

Rolling Shutter CMOS

Image Sensor

Features

http://onsemi.com

•

9.6 MegaPixel Resolution in 3840

2500 Format

2.4

Square Pixels (Shared 4T Pixel Architecture)

2/3 inch Optical Format

Monochrome (SM) Version

20 Frames per Second (fps) at Full Resolution

200 mW / 500 mW Power Consumption at 5 fps / 20 fps

Four Low−Voltage Differential Signaling (LVDS) High Speed Serial

Outputs or One 10−bit CMOS Output

On-chip 10-bit Analog-to-Digital Converter (ADC)

Windowing to Attain Higher Frame Rate

Rolling Shutter

On-chip Fixed Pattern Noise (FPN) Correction

Serial Peripheral Interface (SPI)

Automatic Exposure Control (AEC)

Phase Locked Loop (PLL)

Figure 1. MANO 9600 Package Photograph

High Dynamic Range (HDR)

Dual Power Supply (1.8 V and 3.3 V)

Applications

0°C to 70°C Operational Temperature Range

•

Biometrics (Fingerprinting)

52-pin LCC

•

Machine Vision

500 mW Power Dissipation (LVDS)

•

Inspection

200 mW Power Dissipation (CMOS)

•

Microscopy

These Devices are Pb−Free and are RoHS Compliant

Description

The MANO9600 is a rolling shutter CMOS image sensor with a resolution of 3840 x 2500 pixels.

The high sensitivity 2.4

x 2.4

pixels supports correlated double sampling readout reducing noise and increasing

dynamic range.

A high level of programmability using a four wire serial peripheral interface enables the user to read out specific regions

of interest.

Higher frame rates are achieved with region of interest or sub−sampled readout modes. The sensor has built−in features for

bias control and power supply regulation.

The sensor has on−chip programmable gain amplifiers and 10−bit A/D converters. The integration time and gain parameters

can be reconfigured without any visible image artifact. Optionally the on−chip automatic exposure control loop (AEC) controls

these parameters dynamically. The image’s black level is either calibrated automatically or can be adjusted by adding a user

programmable offset.

The image data interface of the M1−SM part consists of four LVDS lanes running at 620 Mbps, facilitating frame rates up

to 20 frames per second. A separate synchronization and clock channel containing payload information is provided to facilitate

the image reconstruction at the receive end. The M2−SM part provides a parallel CMOS output interface at reduced frame rate

of 5 frames per second.

The MANO 9600 is packaged in a 52−pin LCC package and is available in a monochrome without micro lens.

Contact your local ON Semiconductor office for more information.

This document contains information on a new product. Specifications and information herein are subject to change without notice.

Semiconductor Components Industries, LLC, 2014

February, 2014

−

Rev. P0

Publication Order Number:

NOIM1SM9600A/D
