Oscilent Corporation | 620 - 623 Series Ceramic Resonator
Page 1 of 2
Ceramic Resonator
Series Number
Package
Description
Last Modified
620 ~ 623
.
FEATURES
- Low profile ceramic resonator
- Wide frequency range
- Extended temperature range
- High stability
- Built in load capacitance
- RoHS Compliant
ZTT Ceramic
Low Profile
Jan. 01 2007
.
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
Series No.
620
621
622
623
Type
ZTT-MG
ZTT-MT
ZTT-MX
ZTT-MGL
Frequency
Range
(MHz)
1.79 ~ 6.00
6.00 ~ 13.00
12.00 ~ 20.00
20.01 ~ 25.99
26.00 ~ 60.00
3.00 ~ 8.00
* Other C1 / C2 values available
±0.5%
-20 ~ 80
Frequency
Accuracy
@25°
Operating
Temperature
°C
Stability in
Temperature
(-20 ~ +80°C)
±0.3%
±03%
±0.3%
±0.3%
±0.3%
±0.3%
Aging for
Ten Years
-
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
C1
(pF)
30
30
30
15
5
30
C2
(pF)
30
30
30
15
5
30
.
(1) Input
(2) Ground
(3) Output
IC (MG,MT) : 1/6TC4069UBPx2
IC (MX) : 1/6TC74HCU04x2
VDD : +5V
Series No.
620
621
Type
ZTT-MG
ZTT-MT
Frequency
(MHz)
1.79 ~ 6.00
6.01 ~ 13.00
12.00 ~ 13.00
Dimensions (max.)
W
10.0
10.0
10.0
H
8.0
10.0
12.0
Oscilent Corporation | 620 - 623 Series Ceramic Resonator
Page 2 of 2
622
623
ZTT-MX
ZTT-MGL
13.01 ~ 60.00
3.00 ~ 8.00
10.0
9.0
10.0
5.5
.
PART NUMBER GUIDE
Part Number
Frequency
Load Capacitance
Frequency
Accuracy ( % )
Operating
Temp (
°C
)
Packaging**
622
620 to 623 (see table
above)
- 20.0M
e.g. -12.1M = 12.10 MHz
Range =1.79 ~ 60.0 MHz
- 33
- 03
W
Blank*
=
-20 ~ +80
-N
=
-40 ~ +85
-W
=
-40 ~ +125
- TR
Blank*
= Bulk
-TT
= Ammo
Pack (Qty = 2K)
Blank*
= Standard as
Blank*
= ±0.5%
shown in above Table
-03
= ±0.3%
Custom = Enter
desired value
e.g. -33 = 33pF
NOTE:
Deviations on all parameters available. Please consult Oscilent for details.
DEFINITIONS:
Click on the characteristic names above, for definitions of the particular characteristic.
*STANDARDS:
"Blank" part number selections, indicate standard variables for the particular characteristic.
**PACKAGING:
Click on the packaging name above for Ammo Pack specifications
