The SGA5589Z is a high performance SiGe HBT MMIC Amplifier. A Darling-
ton configuration featuring one-micron emitters provides high F
T
and
excellent thermal performance. The heterojunction increases breakdown
voltage and minimizes leakage current between junctions. Cancellation of
emitter junction non-linearities results in higher suppression of intermodu-
lation products. Only two DC-blocking capacitors, a bias resistor, and an
optional RF choke are required for operation.
Optimum Technology
Matching® Applied
GaAs HBT
GaAs MESFET
InGaP HBT
SiGe BiCMOS
Si BiCMOS
SiGe HBT
GaAs pHEMT
Si CMOS
Si BJT
GaN HEMT
InP HBT
RF MEMS
LDMOS
0
0
1
2
3
4
Frequency (GHz)
5
6
-40
24
32
Features
High Gain: 20.8dB at
1950MHz
Cascadable 50
Operates from Single Supply
Low Thermal Resistance
Package
PA Driver Amplifier
Cellular, PCS, GSM, UMTS
IF Amplifier
Wireless Data, Satellite
Applications
Gain & Return Loss vs. Frequency
V
D
= 3.9 V, I
D
= 60 mA (Typ.)
0
GAIN
Return Loss (dB)
-10
Gain (dB)
ORL
IRL
-20
16
8
-30
Parameter
Small Signal Gain
Min.
21.5
Specification
Typ.
24.0
20.8
18.9
18.2
16.2
32.9
29.2
4000
Max.
26.5
Unit
dB
dB
dB
dBm
dBm
dBm
dBm
MHz
850MHz
1950MHz
2400MHz
850MHz
1950MHz
850MHz
1950MHz
>10dB
Condition
Output Power at 1dB Compression
Output Third Intercept Point
Bandwidth Determined by Return
Loss
Input Return Loss
13.7
dB
1950MHz
Output Return Loss
25.2
dB
1950MHz
Noise Figure
3.4
dB
1950MHz
Device Operating Voltage
3.5
3.9
4.3
V
Device Operating Current
54
60
66
mA
Thermal Resistance
97
°C/W
(Junction - Lead)
Test Conditions: V
S
=8V, I
D
=60mA Typ., OIP
3
Tone Spacing=1MHz, P
OUT
per tone=0dBm, R
BIAS
=68, T
L
=25°C, Z
S
=Z
L
=50
RF MICRO DEVICES®, RFMD®, Optimum Technology Matching®, Enabling Wireless Connectivity™, PowerStar®, POLARIS™ TOTAL RADIO™ and UltimateBlue™ are trademarks of RFMD, LLC. BLUETOOTH is a trade-
