MG200xE
Series
Low Cost, 2W
Compact MiniDIP
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
2W Output Power
•
Compact MiniDIP Case
•
High Efficiency
•
1,500 VDC Isolation
•
Single and Dual Outputs
•
>3.5 MHour MTBF
•
-40°C to +85°C Operation
•
LOW COST
Input
Parameter
Input Voltage Range
Input Filter
Conditions
Min.
3.3 VDC Input 2.97
5 VDC Input 4.50
12 VDC Input 10.80
24 VDC Input 21.60
Internal Capacitor
Conditions
Min.
Typ.
3.3
5.0
12.0
24.0
Max.
3.63
5.50
13.20
26.40
Units
VDC
Output
Parameter
Output Voltage Accuracy
Line Regulation
Load Regulation, See Note 1
Ripple & Noise (20 MHz), See Note 2
Typ.
±2.5
Max.
±1.2
Units
%
%
mV P - P
For V
IN
Change of 1%
See Model Selection Guide
Output Voltage <12 VDC
60
15 VDC, 24 VDC Output
75
5 VDC & 12 VDC Input
3.3 VDC & 24 VDC Input
Conditions
60 Seconds
500 VDC
100 kHz, 0.1V
3.0 kV Isolation
Models
Available
Temperature Coefficient
Output Short Circuit
±0.03
%/°C
Continuous (Autorecovery)
Momentary (1.0 Sec.)
Min.
1,500
1,000
Typ.
Max.
Units
VDC
M
pF
kHz
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
EMI Characteristics
Parameter
EMI Compliance, See Note 4
EMC Compliance, Single Output
EMC Compliance, Dual Output
20
100
Min.
300
Conditions
Conducted
Radiated
Electrostatic Discharge (ESD)
Conditions
Typ.
Max.
Units
CISPR22/EN 55022 Level B
CISPR22/EN 55022 Level B
EN 61000-4-2 Level B Contact ±8 kV
EN 61000-4-2 Level B Contact ±6 kV
Max.
+85
+125
95
Units
°C
°C
%
Environmental
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
Case Size
Case Material
Weight
Min.
Typ.
Ambient
-40
+25
-55
Free Air Convection
RH, Non-condensing
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
0.787 x 0.394 x 0.323 Inches (20.0 x 10.0 x 8.2 mm)
Non-Conductive Black Plastic (UL-94V0)
0.08 Oz (2.4g)
Conditions
MIL HDBK 217F, 25°C, Gnd Benign
Conditions
3.3 VDC Input
5 VDC Input
12 VDC Input
24 VDC Input
1.5 mm From Case For 10 Sec
Min.
3.5
Min.
-0.7
-0.7
-0.7
-0.7
Typ.
Max.
Units
MHours
Units
VDC
°C
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
Lead Temperature
Typ.
Max.
5.0
9.0
18.0
30.0
300
Caution: Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
www.micropowerdirect.com
Model Selection Guide
Input
Model
Number
MG203S-05E
MG205S-05E
MG205S-12E
MG205S-15E
MG205D-05E
MG205D-09E
MG205D-12E
MG205D-15E
MG212S-05E
MG212S-12E
MG212S-24E
MG212D-05E
MG212D-09E
MG212D-12E
MG212D-15E
MG224S-05E
MG224S-09E
MG224S-12E
MG224D-05E
MG224D-09E
MG224D-15E
Voltage
(VDC)
Current
(mA)
Nominal
Range
Full-Load No-Load
3.3
2.97 - 3.63
757
40
5
4.5 - 5.5
500
25
5
4.5 - 5.5
476
25
5
4.5 - 5.5
476
25
5
4.5 - 5.5
500
25
5
4.5 - 5.5
482
25
5
4.5 - 5.5
476
25
5
4.5 - 5.5
476
25
12
10.8 - 13.2
205
15
12
10.8 - 13.2
198
15
12
10.8 - 13.2
198
15
12
10.8 - 13.2
205
15
12
10.8 - 13.2
198
15
12
10.8 - 13.2
196
15
12
10.8 - 13.2
198
15
24
21.6 - 26.4
101
8
24
21.6 - 26.4
99
8
24
21.6 - 26.4
99
8
24
21.6 - 26.4
101
8
24
21.6 - 26.4
99
8
24
21.6 - 26.4
99
8
Voltage
(VDC)
www.micropowerdirect.com
Output
Current
(mA, Max)
5.0
5.0
12.0
15.0
±5.0
±9.0
±12.0
±15.0
5.0
12.0
24.0
±5.0
±9.0
±12.0
±15.0
5.0
9.0
12.0
±5.0
±9.0
±15.0
400
400
167
133
±200
±111
±83
±67
400
167
83
±200
±111
±83
±67
400
222
167
±200
±111
±67
Output
Load
Capacitive Efficiency Fuse Rating
Load
Slow-Blow
Current Regulation
(%, Typ)
(µF Max)
(mA)
(mA, Min)
% Typ.
40.0
12.0
220
80
1,500
40.0
12.0
220
80
1,000
17.0
8.0
220
84
1,000
13.0
7.0
220
84
1,000
±20.0
12.0
100
80
1,000
±11.0
9.0
100
83
1,000
±8.0
8.0
100
84
1,000
±7.0
7.0
100
84
1,000
40.0
12.0
220
81
500
17.0
8.0
220
84
500
8.0
6.0
220
84
500
±20.0
12.0
100
81
500
±11.0
9.0
100
84
500
±8.0
8.0
100
85
500
±7.0
7.0
100
84
500
40.0
12.0
220
82
250
22.0
9.0
220
84
250
17.0
8.0
220
84
250
±20.0
12.0
100
82
250
±11.0
9.0
100
84
250
±7.0
7.0
100
84
250
Notes:
1. Output load regulation is specified for a load change of 10% to 100%.
2. When measuring output ripple, it is recommended that an external 1
µF
ceramic capacitor & 10
µF
electrolytic
capacitor be placed in parallel from the +Vout pin to the -Vout pin for single output models, or from each output
to common for dual output models.
3. Operation at no load will not damage these units, however, they may not meet all specifications.
4. These converters are specified for operation without external components. However, in some applications the
addition of input/output capacitors will enhance stability and reduce output ripple. The simple connection shown
below will typically meet EN 55022 Class B. For dual output units, a capacitor should be connected from each
output to common.
Derating Curve
V
IN
3.3 VDC
5 VDC
12 VDC
24 VDC
C
1
4.7
µF/50V
4.7
µF/50V
2.2
µF/50V
1.0
µF/50V
L
1
6.8
µH
6.8
µH
6.8
µH
6.8
µH
V
OUT
5 VDC
9 VDC
12 VDC
15 VDC
24 VDC
±5
VDC
±7
VDC
±9
VDC
±12
VDC
±15
VDC
C
2
10
µF
4.7
µF
2.2
µF
1.0
µF
1.0
µF
4.7
µF
2.2
µF
2.2
µF
1.0
µF
0.47
µF
Mechanical Dimensions
5. It is recommended that a fuse be used on the input of a power supply for
protection. See the Model Selection table above for the correct rating.
Pin Connections
Pin
1
7
8
Single
-V
IN
NC
-V
OUT
Dual
-V
IN
NC
Common
Pin
9
11
14
Single
+V
OUT
No Pin
+V
IN
Dual
+V
OUT
-V
OUT
+V
IN
NC = No Connection
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx =
±
0.02 (
±
0.50)
•
Pin 1 is marked by a “dot” or indentation on the unit
FAX: (781) 344-8481
•
TEL: (781) 344-8226
•
E-Mail: sales@micropowerdirect.com
