PF2200 Series
TO-220 Power Thin Film Resistors
•
•
•
•
•
•
•
•
•
TO-220 Housing
Rated Power to 50 Watts
Resistances from 0.02 to 51K Ohms
High Stability Film Resistance Elements
Resistance Tolerance to ±0.1%
TCR to ±50ppm/°C
Low Inductance ( <10nH )
Excellent Pulse Handling
Isolated Mounting Tab
SPECIFICATIONS
Type
PF2205
PF2203
PF2202
Power Rating
Heatsink
1
Free Air
2
Thermal
Resistance
Resistance Range
3
Min
0.02W
0.02W
0.02W
Max
51KW
51KW
51KW
Tolerances
4
±1% and ±5%
±5% below 0.1W
±1% and ±5%
±5% below 0.1W
±1% and ±5%
±5% below 0.1W
1
2
Temperature
Coefficients
±50ppm/°C ( R≥10W
)
±100ppm/°C ( 0.1W
≤ R <
10W )
±250ppm/°C ( R < 0.1W
)
±50ppm/°C ( R≥10W
)
±100ppm/°C ( 0.1W
≤ R <
10W )
±250ppm/°C ( R < 0.1W
)
±50ppm/°C ( R≥10W
)
±100ppm/°C ( 0.1W
≤ R <
10W )
±250ppm/°C ( R < 0.1W
)
50W
35W
20W
1W
1W
1W
2.3°C/W
3.3°C/W
5.9°C/W
Power rating based on 25°C Flange Temperature
Power rating based on 25°C Ambient Temperature
3
Consult Factory for Higher or Lower Values
4
Consult Factory for possible tighter tolerances
Specification
Temperature Range
Dielectric Strength
Max. Operating Voltage
Insulation Resistance
Terminal Finish
Inductance
Flammability
Value
-55°C to +175°C
2000 VAC
P
*
R
( 500V MAX )
>1000 Meg-Ohm
Tin Plated Copper
PF2202 / PF2203 8.38 nH, PF2205 9.65 nH
UL94 V-0
Mass
2.1g
Part Description: Part Type - Resistance - Tolerance - TCR
Example: PF2203 0.5 Ohm 1% 100ppm
© Riedon, Inc.
Ordering Information
(626) 284-1704
Riedon Inc.
300 Cypress Avenue
Alhambra CA 91801
(626) 284-9901
www.riedon.com
sales@riedon.com
Revised: 202005_003
PF2200 Series
TO-220 Power Thin Film Resistors
SPECIFICATIONS
(continued)
Environmental Performance
Load Life
Humidity Resistance
Temperature Cycle
Solder Heat
Vibration
DR
±1%
±1%
±0.25%
±0.1%
±0.25%
Test Conditions
25°C, 90 min ON, 30 min OFF, 1000 hr
40°C, 90-95% RH, DC 0.1W, 1000 hr
-55°C for 30 min, +155°C for 30 min, 5 cycles
+350 / -5°C 3s
IEC60068-2-6
Power Derating
% Power
100
80
60
40
20
0
-50
0
+175
°C
50
100
150
Flange Temperature (C)
200
+25
°C
Power Rating Notes -
The PF2200 Series Thin Film Resistors must be attached to a
suitable heatsink. Without a heatsink the maximum power rating
is 1W ( 1/2W for the PF2201 ). The maximum internal resistor
temperature is 175°C.
To specify an appropriate heatsink use the following formula :
Where:
R
H
H
=
R
qH
R
qR
= Thermal Resistance of Resistor ( °C/W )
T
MAX
= Maximum Temperature of Resistor ( °C )
T
A
= Ambient Temperature of Heatsink ( °C )
P = Power Through Resistor ( W )
T
MAX
- (
P
*
R
H
R
) -
T
A
P
= Thermal Resistance of Heatsink ( °C/W )
A
D
G
C
N
Dimension
mm
10.1
15.0
4.5
3.6
15.5
4.0
3.0
2.75
0.5
0.75
1.5
5.08
1.5
16.0
tol.
(±mm)
0.2
0.2
0.2
0.1
1.0
0.5
0.2
0.2
0.05
0.05
0.05
0.1
0.05
0.50
inches
0.40
0.60
0.18
0.14
0.61
0.16
0.12
0.11
0.02
0.03
0.06
0.20
0.06
0.63
tol.
(±inches)
0.008
0.008
0.008
0.004
0.04
0.02
0.008
0.008
0.002
0.002
0.002
0.004
0.002
0.02
A
B
C
B
P
D
E
F
G
L
F
E
K
J
H
H
J
K
L
M
N
P
M
Mounting Notes -
The PF2200 Series Thin Film Resistors must be attached to a suitable heatsink. Mount resistor using thermal grease to a clean, flat surface. Use
a compression washer to provide 150 to 300 pounds ( 665 to 1330N ) of mounting force. Torque mounting screw to 8 in-lbs ( 0.9 N-m ).
Mounting tab is isolated from both pins.
© Riedon, Inc.
Riedon Inc.
300 Cypress Avenue
Alhambra CA 91801
(626) 284-9901
www.riedon.com
sales@riedon.com
Revised: 202005_003
(626) 284-1704
PF2200 Series
TO-220 Power Thin Film Resistors
PULSE ENERGY DURABILITY
Pulse Energy Durability
Pulse Peak Power (W)
1000k
100k
10k
1k
100
10
10n 100n 1u
10u
100u 1m
10m 100m
1
10
200W
PF2202_10ohm-1%
Tentative continuous-pulse power allowance at
duty 0.01. Load life test will be necessary in
actual equipment, Because curve will be changed
by resistance, repetition, duty and operating
temperature. Dotted shows estimation.
Pulse Energy Durability
Pulse Peak Power (W)
1000k
100k
10k
1k
100
20W
10
10n 100n 1u
10u
100u 1m
35W
10m 100m
1
10
400W
PF2203_10ohm-1%
Tentative continuous-pulse power allowance at
duty 0.01. Load life test will be necessary in
actual equipment, Because curve will be changed
by resistance, repetition, duty and operating
temperature. Dotted shows estimation.
Pulse Energy Durability
Pulse Peak Power (W)
1000k
100k
10k
1k
100
10
10n 100n 1u
10u
100u 1m
400W
50W
10m 100m
1
10
PF2205_10ohm-1%
Tentative continuous-pulse power allowance at
duty 0.01. Load life test will be necessary in
actual equipment, Because curve will be changed
by resistance, repetition, duty and operating
temperature. Dotted shows estimation.
