DESCRIPTION
NEW DRAWING
Changed housing material to PA6T from PBT
DATE
10/11/2005
1/10/2006
3.2 0.13
14.4 0.57
3.00 0.12
1
5.7 0.22
6.5 0.26
15.7 0.62
2.5 0.10
13.5 0.53
10.0 0.39
1.500 0.06
(2 PLCS)
1.50 0.06
2.0 0.08
4.0 0.16
5.00X5.00
1
2.9 0.11
(TYP)
3.50 0.14
5.00 0.20
2.5 0.10
(2 PLCS)
3
2
4.20 0.17
1.6 0.06
(2 PLCS)
4.5 0.18
13.0 0.51
9.0 0.35
2.00 0.08
8.20 0.32
5.0 0.20
1.0 0.04
8.5 0.33
PCB LAYOUT
TOP VIEW
MODEL NO.
SCHEMATIC
PJ-015B-SMT
1
3
2
SPECIFICATIONS:
RATING: 16V DC @ 2.5A
CONTACT RESISTANCE: 30m OHMS MAX
INSULATION RESISTANCE: 50M OHMS MIN: 100V DC
VOLTAGE WITHSTAND: 500V AC R.M.S. FOR 1 MINUTE
LIFE: 5,000 CYCLES
MATERIAL
CENTER PIN
TERMINAL 1
TERMINAL 2
PC FILE NAME:
8.20 0.32
11.0 0.43
TOLERANCE:
X.X ±0.2mm
X.XX ±0.1mm
X.XXX ±0.05mm
2
3
3.75X5.00
(2 PLCS)
1.90 0.07
RoHS
20050 SW 112th Ave.
Tualatin, OR 97062
Phone: 503-612-2300
800-275-4899
Fax: 503-612-2383
Website: www.cui.com
PLATING
Nickel
Silver
Silver
Silver
TITLE:
CENTER PIN DIAMETER 2.5mm Dia.
Copper
Brass
Copper Alloy
Brass
PA6T
DC POWER JACK
PJ-015B-SMT
APPROVED BY:
UNITS:
REV:
B
PART NO.
MM [INCHES]
SCALE:
PJ-015B-SMT
COPYRIGHT 2010 BY CUI INC.
TERMINAL 3
HOUSING
DRAWN BY:
ZRJ
2:1
