35363-0860 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 35363-0860

35363-0860: Description8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER; CategoryThe connector; File Size32KB，3 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

35363-0860 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	35363-0860	-	-	View	Buy Now

35363-0860 Overview

8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER

35363-0860 Parametric

Parameter Name	Attribute value
Contact materials	BRASS
Terminal spacing	2 mm
Total number of contacts	8
Processing package description	LEAD FREE
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	35363
Contact surface matching	TIN OVER COPPER
Contact coated terminals	TIN OVER COPPER
Connection Type	TWO PART BOARD CONNECTOR
Connector male and female	MALE
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of load rows	1
Terminal type	SOLDER
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0156

General Information

Part Number:

76650-0156

Manufacturer:

Title

Description:

Product Family:

Certificates:

Molex / Waldom

Sherlock Connector Kit

Secure and Space Saving Vertical and Right Angle Header, and Receptacle

Sherlock™

(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

Originally developed for PC monitor applications, this new 2.0mm pitch system

can also be used for other applications that require space savings and secure

locking features. The Sherlock system utilizes Molex's proven 50212 terminal,

along with a positive lock housing.

Wire to Board

2.0mm (.079")

Receptacles and Headers

Right Angle and Vertical

2, 3, 4, 6 and 8

(0.5 to 2) Amps - Dependant on Wire Gauge

125 Volts

30-24 AWG

For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com

Page 1 of 3

35363-0860 Related Products

	35363-0860	35362-0250	35507-0800	57176-5000	76650-0156	35363-0260	35507-0200	35362-0850
Description	8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	8 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	8 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	8 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	8 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	2 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	MOLEX - 35362-0850 - WIRE-BOARD CONNECTOR; HEADER; 8POS; 2MM
Total number of contacts	8	8	8	8	8	2	2	-
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes	Yes	-
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	-
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	-
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	-
Manufacturer Series	35363	35507	35507	35507	35507	35363	35507	-
Connection Type	TWO PART BOARD CONNECTOR	Dual board connector	Dual board connector	Dual board connector	Dual board connector	TWO PART BOARD CONNECTOR	Dual board connector	-
Connector male and female	MALE	Jack	Jack	Jack	Jack	MALE	Jack	-
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	-
Installation type	BOARD	CABLE	CABLE	CABLE	CABLE	BOARD	CABLE	-
Number of load rows	1	1	1	1	1	1	1	-
Terminal type	SOLDER	riveting	riveting	riveting	riveting	SOLDER	riveting	-
UL flammability code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	-
Shell style	-	socket	socket	socket	socket	-	socket	-
