FSL110R4: DescriptionPower Field-Effect Transistor, 3.5A I(D), 100V, 0.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-205AF, HERMETIC SEALED, METAL CAN-3; CategoryDiscrete semiconductor The transistor; File Size89KB，9 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/

Download Datasheet Parametric View All

FSL110R4 Overview

Power Field-Effect Transistor, 3.5A I(D), 100V, 0.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-205AF, HERMETIC SEALED, METAL CAN-3

FSL110R4 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Fairchild
Parts packaging code	BCY
package instruction	HERMETIC SEALED, METAL CAN-3
Contacts	4
Reach Compliance Code	compli
ECCN code	EAR99
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	100 V
Maximum drain current (Abs) (ID)	3.5 A
Maximum drain current (ID)	3.5 A
Maximum drain-source on-resistance	0.6 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-205AF
JESD-30 code	O-MBCY-W3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	METAL
Package shape	ROUND
Package form	CYLINDRICAL
Polarity/channel type	N-CHANNEL
Maximum power dissipation(Abs)	6 W
Maximum pulsed drain current (IDM)	10.5 A
Certification status	Not Qualified
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	WIRE
Terminal location	BOTTOM
transistor applications	SWITCHING
Transistor component materials	SILICON
Base Number Matches	1

Preview

Download Datasheet

View All

FSL110D, FSL110R

Data Sheet

October 1998

File Number 4224.3

3.5A, 100V, 0.600 Ohm, Rad Hard, SEGR

Resistant, N-Channel Power MOSFETs

The Discrete Products Operation of Intersil has developed a

series of Radiation Hardened MOSFETs speciﬁcally

designed for commercial and military space applications.

Enhanced Power MOSFET immunity to Single Event Effects

(SEE), Single Event Gate Rupture (SEGR) in particular, is

combined with 100K RADS of total dose hardness to provide

devices which are ideally suited to harsh space

environments. The dose rate and neutron tolerance

necessary for military applications have not been sacriﬁced.

The Intersil portfolio of SEGR resistant radiation hardened

MOSFETs includes N-Channel and P-Channel devices in a

variety of voltage, current and on-resistance ratings.

Numerous packaging options are also available.

This MOSFET is an enhancement-mode silicon-gate power

ﬁeld-effect transistor of the vertical DMOS (VDMOS)

structure. It is specially designed and processed to be

radiation tolerant. The MOSFET is well suited for

applications exposed to radiation environments such as

switching regulation, switching converters, motor drives,

relay drivers and drivers for high-power bipolar switching

transistors requiring high speed and low gate drive power.

This type can be operated directly from integrated circuits.

Reliability screening is available as either commercial, TXV

equivalent of MIL-S-19500, or Space equivalent of

MIL-S-19500. Contact Intersil for any desired deviations

from the data sheet.

Features

• 3.5A, 100V, r

DS(ON)

= 0.600

Ω

• Total Dose

- Meets Pre-RAD Speciﬁcations to 100K RAD (Si)

• Single Event

- Safe Operating Area Curve for Single Event Effects

- SEE Immunity for LET of 36MeV/mg/cm

with

up to 80% of Rated Breakdown and

of 10V Off-Bias

• Dose Rate

- Typically Survives 3E9 RAD (Si)/s at 80% BV

DSS

- Typically Survives 2E12 if Current Limited to I

• Photo Current

- 0.3nA Per-RAD(Si)/s Typically

• Neutron

- Maintain Pre-RAD Speciﬁcations

for 3E13 Neutrons/cm

- Usable to 3E14 Neutrons/cm

Symbol

Ordering Information

RAD LEVEL

10K

100K

SCREENING LEVEL

Commercial

TXV

Commercial

TXV

Space

PART NUMBER/BRAND

FSL110D1

FSL110D3

FSL110R1

FSL110R3

FSL110R4

Package

TO-205AF

Formerly available as type TA17616.

FSL110D, FSL110RH Rev. A
