BUX48

Description
15 A, 450 V, NPN, Si, POWER TRANSISTOR, TO-204AA
CategoryDiscrete semiconductor    The transistor
File Size174KB，8 Pages
ManufacturerMotorola ( NXP )
Websitehttps://www.nxp.com
Download Datasheet Parametric Compare View All

BUX48 Online Shopping

Suppliers Part Number Price MOQ In stock
BUX48 - - View Buy Now

BUX48 Overview

15 A, 450 V, NPN, Si, POWER TRANSISTOR, TO-204AA

BUX48 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerMotorola ( NXP )
package instructionFLANGE MOUNT, O-MBFM-P2
Reach Compliance Codeunknown
Shell connectionCOLLECTOR
Maximum collector current (IC)15 A
Collector-based maximum capacity350 pF
Collector-emitter maximum voltage400 V
ConfigurationSINGLE
Minimum DC current gain (hFE)8
JEDEC-95 codeTO-204AA
JESD-30 codeO-MBFM-P2
JESD-609 codee0
Number of components1
Number of terminals2
Maximum operating temperature200 °C
Package body materialMETAL
Package shapeROUND
Package formFLANGE MOUNT
Polarity/channel typeNPN
Maximum power consumption environment175 W
Maximum power dissipation(Abs)175 W
Certification statusNot Qualified
surface mountNO
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formPIN/PEG
Terminal locationBOTTOM
transistor applicationsSWITCHING
Transistor component materialsSILICON
Nominal transition frequency (fT)5 MHz
Maximum off time (toff)2400 ns
Maximum opening time (tons)900 ns
VCEsat-Max5 V
