SM-SM50 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > SM-SM50

Preview

SM-SM50: DescriptionAdapter, SMA-M to SMA-M 50W DC to 18 GHz; File Size51KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet View All

SM-SM50 Overview

Adapter, SMA-M to SMA-M 50W DC to 18 GHz

Preview

Download Datasheet

View All

Coaxial

Adapter,

SMA-M to SMA-M

50Ω DC to 18 GHz

Features

EW!

SM-SM50

• flat response

• excellent VSWR, 1.10: typ. up to 12.4 GHz

and 1.15:1 typ. up to 18 GHz

• low cost adapters, available from stock

• rugged stainless steel body, gold plated

Applications

CASE STYLE: DJ951

• interconnection of RF cables and equipment

Electrical Specifications T

AMB

=25°C

MODEL

NO.

CONNECTOR

TYPE

CONN 1

CONN 2

SMA-MALE

FREQUENCY

(GHz)

-f

DC-18

DC-8

GHz

1.12

VSWR (:1)

Max.

DC-12.4

GHz

1.30

DC-18

GHz

1.40

PRICE

Qty.

(1-49)

5.95

SM-SM50

Maximum Ratings

Operating Temperature

Storage Temperature

-55°C to 100°C

Outline Drawing

Outline Dimensions

(

inch

)

.312

7.92

.36

.87

9.14 22.10

.312

7.92

.215

5.46

.15

3.81

wt.

grams

4.8

Mini-Circuits

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

REV. A

M90500

SM-SM50

ED-10283

YB/CP

040109

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

ISO 9001 CERTIFIED
