Coaxial
Matching Pad
50/75Ω
DC to 3000 MHz
Maximum Ratings
Operating Temperature
Storage Temperature
-45°C to 100°C
-55°C to 100°C
TYPE-N
EW!
N
UNMP-5075
Features
•
•
•
•
•
•
minimum loss pad
wideband coverage, DC to 3000 MHz
0.5 watt rating
rugged construction
off-the-shelf availability
very low cost
CASE STYLE: FF779
CONNECTOR: 75Ω M-N
50Ω F-N
PRICE: $29.95 ea. QTY (1-9)
Applications
• impedance matching
Outline Drawing
Electrical Specifications
MODEL
NO.
FREQUENCY
(MHz)
f
L
-f
U
UNMP-5075
DC-3000
Nom.
5.7±0.15
ATTENUATION*
(dB)
Flatness** Max.
L
0.2
M
0.3
U
0.4
L
1.10
VSWR
(:1)
Max.
M
1.30
U
1.5
POWER
(W)
0.5
U= 1000 to 3000 MHz
* Attenuation varies by 0.3 dB max. over temperature.
** Flatness= variation over band divided by 2
L=DC to 100 MHz
M= 100 to 1000 MHz
Typical Performance Data
Outline Dimensions (
B
.700
17.78
D
2.11
53.59
E
.813
20.65
wt.
grams
65.0
inch
mm
)
FREQUENCY
(MHz)
1.00
5.00
10.00
50.00
100.00
300.00
500.00
800.00
1000.00
1200.00
1500.00
1800.00
2000.00
2600.00
3000.00
ATTENUATION
(dB)
5.80
5.80
5.80
5.84
5.86
5.88
5.88
5.88
5.87
5.81
5.82
5.79
5.79
5.64
5.81
VSWR (:1)
50
Ω
75
Ω
1.00
1.00
1.00
1.00
1.00
1.01
1.02
1.04
1.04
1.05
1.14
1.17
1.14
1.36
1.24
1.00
1.00
1.00
1.01
1.01
1.03
1.05
1.07
1.09
1.11
1.14
1.17
1.20
1.30
1.40
UNMP-5075
INSERTION LOSS
7.0
6.8
6.6
6.4
6.2
6.0
5.8
5.6
5.4
5.2
5.0
0
500
1.5
-40°C
+25°C
+100°C
1.4
VSWR
1.3
1.2
1.1
1.0
1000
1500
2000
2500
3000
0
500
-40°C
INSERTION LOSS (dB)
UNMP-5075
VSWR
+25°C
+100°C
1000
1500
2000
2500
3000
FREQUENCY (MHz)
FREQUENCY (MHz)
Mini-Circuits
MP1
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
ISO 9001 & ISO 14001
Certified
REV. OR
M90870
ED-11538
UNMP-5075
WP/TD/CP/AM
040719
