F-213
BTSW–110–01–T–D
MNT–120–BK–T
SNT–100–BK–T–H
SNT–100–BK–G
(2,54 mm) .100"
BTMM–106–01–T–S
JL–400–25–T
SNT, MNT, 2SN, SNM, PK, JL, BTMM, BTSW SERIES
SHUNTS & JUMPERS
SPECIFICATIONS
SNT
SNT
100
BODY
COLOR
PLATING
OPTION
HANDLE
OPTION
JL
For complete specifications
see www.samtec.com?SNT
Insulator Material:
Glass Filled Polyester
Contact Material:
Phosphor Bronze
Current Rating:
2.5A/Contact
Operating Temp Range:
-55°C to +125°C
Contact Resistance:
5 mΩ
Insertion Depth:
(4,32 mm) .170" min.
Lead Size accepted:
(0,64 mm) .025" SQ
Insertion Force:
(Single contact only)
33 oz (9,17 N) average
Withdrawal Force:
(Single contact only)
27 oz (7,51 N) average
RoHS Compliant:
Yes
–BK
= Black
(2,54)
.100
= Orange
–OR
–RD
= Red
= 10µ" (0,25 µm)
Gold
–G
–T
= Tin
= Handle
(Black Only)
–H
Insulation
is white
Teflon
A
(0,64) .025
DIA REF
(6,10)
.240
–BL
(2,54)
.100
(5,08)
.200
(2,54)
.100
(14,00)
.550
(3,18)
.125
= Blue
–YW
= Yellow
Note:
Other Gold plating
options available.
Contact Samtec.
(6,10)
.240
MNT
For complete specifications
see www.samtec.com?MNT
Same as SNT except:
Current Rating:
2A/Contact @ 80°C ambient
Working Voltage:
450 VAC
BTMM
MNT
1
NO. OF
POSITIONS
BODY
COLOR
PLATING
OPTION
(2,57)
.101
(0,50)
.020
SQ
(4,00)
.157
2SN
–S
For complete specifications
see www.samtec.com?2SN
Same as SNT except:
Insertion Depth:
(2,29 mm) .090" minimum
Lead Size accepted:
(0,51 mm) .020" SQ
02 thru 20
(2,54)
.100
(5,08)
.200
–BK
= Black
Note:
Some lengths,
styles and options
are non-standard,
non-returnable.
–G
= 10µ" (0,25 µm) Gold
(2,60)
.102
(4,00)
.157
(8,00) .315
2SN mates with:
TMMH, TMM,
MTMM, MMT, TW,
LTMM, ZLTMM, TSH, EHT
–T
= Tin
(2,54) .100 X No. of Positions
(6,10)
.240
SNM
For complete specifications
see www.samtec.com?SNM
Same as SNT except:
Contact Resistance:
10 mΩ
Insertion Depth:
(3,43 mm) .135" minimum
Lead Size accepted:
(0,46 mm) .018" SQ
SNT/MNT mates with:
TSW, HTSW, MTSW, HMTSW, TLW,
DW, EW, ZW, HW, TSM, BST, PHT
–D
For complete
specifications see
www.samtec.com?BTMM
BTSW
2SN
(3,99) .157
SNM
PK
(0,64)
.025
SQ
(2,69)
.106
(5,08)
.200
SNM mates with:
TMS, MTMS, DWM
–S
Part No.
2SN–BK–G
(2,00) .0787
(3,30)
.130
JL
For complete specifications
see www.samtec.com?JL
Part No.
A
JL–100–25–T
(2,54) .100
JL–250–25–T
(6,35) .250
JL–300–25–T
(7,62) .300
JL–400–25–T
(10,16) .400
JL–500–25–T
(12,70) .500
JL–600–25–T
(15,24) .600
JL–1000–25–T
(25,40) 1.000
(1,02)
.040
(2,54)
.100
(1,27)
.050
Part No.
A
B
(2,80)
.110
B
A
(4,45)
.175
(0,64)
PK–01–06
.025 (5,84)
SQ .230
(0,51)
PK–01–07
.020 (3,18)
SQ .125
(5,08)
(2,54) .200
.100
(10,16) .400
(2,00)
.0787
Part No.
SNM–100–BK–G
Insulator Material:
Natural Thermoplastic
Note:
Order per wheel.
6 pins per wheel.
–D
For complete
specifications see
www.samtec.com?BTSW
WWW.SAMTEC.COM
