Ultra-small Contact Image Sensor Heads, covering
the character recognition
LSH2001-AA10A
Easy to mount on whatever sets because of its small size, this is the device best suitable for whatever detecting thanks to its
deep focus point and high recognition accuracy.
Applications
Detection sets (e.g. surface, paper edge, paper type)
Features
1） Its deep focus point enables scanning of the object without close contact to the glass bed of scanner, so that both the
scanned object and the scanner bed won’t be damaged.
2）Screw holes and the alignment pin are provided for convenience of mounting.
3）16.25mm read width (40mm total width)
Dimensions
(Unit : mm)
40±0.5
35
29
(Reading Width)
16.25
3
+0
2.5
.1
0
0 .1
0
Max.15
12.68 (Focus Point)
11.68 (Surface Level)
2
−
.4
φ
2
2
Scanning Line
Paper Feed Direction
-
1.5
−φ
(2.5)
No.130 Pixel
No.1 Pixel
3.25
8
8.18 (Focus Point)
7.18 (Surface Level)
4−C0.5
Pin No.
Signal
Pin No.
Signal
No.11
No.1
No.1
No.2
No.3
No.4
No.5
No.6
GND
Ao
GND
GND
G-LED
V-LED
No.7
No.8
No.9
No.10
No.11
CLK
SI
GND
GND
VDD
4
−
R1
(NOTE 1) Deflection at the top of glass : ±0.5
(NOTE 2) It is possible to design ±0.2 tolerance.
9.2±0.5
13.45
2
−φ
1
.5
- 0
0
.1
(Connector No.)
Housing : SHR-11V-S-B
Base
: SM11B-SRSS-G-TB
14
6
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
1/4
9.2
2011.03 - Rev.B
LSH2001-AA10A
Characteristics
Parameter
Effective scanning width
Primary scan dot density
Total dot number
Power supply voltage
Scanning speed
Clock frequency
Maximum dynamic range
Minimum dynamic range
Dark output
Operating temperature
Symbol
−
−
−
Data Sheet
Typ.
16.25
200
128
3.3
0.1
8
1.0
0.5
0.8±0.1
5 to 45
Unit
mm
dpi
dots
V
ms / line
MHz
V
V
V
°C
V
DD
SLT
CLK
VRMax.
VRMin.
Vod
−
Pin
assignments
No.
1
2
3
4
5
6
7
8
9
10
11
12
Circuit
GND
Ao
GND
V
REF
R-GND
V-LED
CLK
SP
GND
GND
V
DD
NC
I/O
I
O
I
I
I
I
I
I
I
I
I
−
Functions
Ground
Analog Output
Ground
Reference Voltage
LED ground
LED power supply
Clock
Start Pulse
Ground
Ground
Power Supply
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
2/4
2011.03 - Rev.B
LSH2001-AA10A
Timing
chart
(a) CLK Timing Chart
1/fCLK
twCLK
twCLK
Data Sheet
50%
50%
50%
50%
CLK
50%
50%
ts
SI
tSETUP
tHOLD
Ao
1pixel
2pixel
(b) Data Output Timing Chart
After turning on the SP pulse, the analog output shape starts from the setting up point of 65 clock pulse.
1
2
65
66
67
208
CLK
SP
Ao
Vref Output Period (64pixels)
1 to 64clock
Analog Output Period
1 to 144pixels
Note) Output blank part cannot be used as the analog output standard level.
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
3/4
2011.03 - Rev.B
LSH2001-AA10A
Inner
circuit
V
DD
Data Sheet
1μF x 1
GND
SP
ANALOG MEMORY CIRCUIT
1
144
CLK
Ao
V
REF
V
LED
R
GND
Peripheral
circuit
Contact Image Sensor Heads
5
6
2
4
11
8
7
1,3,9,10
C2
R3
C1
R
R2
R1
C3
C5
C4
R-GND
VLED
Ao
V
REF
V
DD
SP
CLK
GND
∗
R1=R2=100Ω
R3=100kΩ
C1=C5=47μF
C2=100pF
C3=100μF, C4=0.1μF
Please adjust the value of resistance to fit your interface circuit.
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
4/4
2011.03 - Rev.B
