Ultra-Reliable
High Pass Filters
1300 to 5500 MHz
Maximum Ratings
Operating Temperature
Storage Temperature
-55°C to 100°C
-55°C to 100°C
EW!
N
VHP-SERIES
Features
•
•
•
•
rugged unibody construction
pass band insertion loss, 1.0 dB typ.
high power handling, up to 14W
very low cost
CASE STYLE: FF704
PRICE: $29.95 ea. QTY (1-9)
Applications
• sub-harmonic rejection of VCO
Outline Drawing
Electrical Specifications (T
AMB
=25°C)
MODEL
NO.
STOP BAND (MHz)
(loss >40 dB)
VHP-9R5
VHP-16
VHP-19
VHP-26
VHP-39
DC-600
DC-1030
DC-1450
DC-1500
DC-2000
(loss >20 dB)
750
1300
1650
2000
3050
fco, MHz
Nom.
(loss 3 dB)
Typ.
950
1580
1995
2570
3900
PASSBAND
(MHz)
(loss < 1.3 dB)
1300-3500
1900-2700
2300-5500
3000-7000
4600-5500
VSWR (:1)
Stopband
Typ.
18
18
18
18
18
Passband
Typ.
1.3
1.3
1.3
1.4
1.3
POWER
INPUT*
(W)
Pmax.
14
14
10
10
10
* Derate linearly to 0.4 x Pmax. at 100°C
Outline Dimensions (
inch
)
mm
B
D
.461
1.42
11.71 36.07
E
wt.
.312 grams
7.92
10
Typical Performance Data/Curves
Freq.
(MHz)
1.00
100.00
300.00
500.00
600.00
750.00
950.00
1300.00
3500.00
4500.00
Insertion
Loss (dB)
109.09
77.03
69.91
59.22
43.87
24.51
3.18
0.94
0.69
2.21
VSWR
(:1)
273.43
114.28
66.79
47.03
38.78
23.57
2.06
1.23
1.62
3.67
VHP-9R5
INSERTION LOSS
VHP-9R5
VSWR
110
100
90
80
70
60
50
40
30
20
10
0
0
1000
INSERTION LOSS (dB)
VSWR
500 1000 1500 2000 2500 3000 3500 4000 4500
FREQUENCY (MHz)
100
10
1
0
500 1000 1500 2000 2500 3000 3500 4000 4500
FREQUENCY (MHz)
Freq.
(MHz)
1.00
500.00
1030.00
1300.00
1580.00
1900.00
2300.00
2700.00
3000.00
5000.00
Insertion
Loss (dB)
101.37
62.34
44.28
23.15
2.82
1.12
0.80
1.01
1.47
1.03
VSWR
(:1)
330.92
68.33
40.07
24.17
2.03
1.27
1.17
1.74
2.45
1.97
110
100
90
80
70
60
50
40
30
20
10
0
0
1000
VHP-16
INSERTION LOSS
1000
VHP-16
VSWR
INSERTION LOSS (dB)
VSWR
2000
3000
4000
5000
100
10
1
0
1000
2000
3000
4000
5000
FREQUENCY (MHz)
FREQUENCY (MHz)
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
ISO 9001 CERTIFIED
REV. A
M92137
VHP-9R5 ED-10545B/7
VHP-16 ED-10545B/2
VHP-19 ED-10545B/6
VHP-26 ED-10545B/11
VHP-39 ED-10545B/12
WZ/AD/CP
040429
Page 1 of 2
VHP-SERIES
Freq.
(MHz)
1.00
500.00
1000.00
1250.00
1450.00
1650.00
1995.00
2300.00
5500.00
9000.00
Insertion
Loss (dB)
93.02
48.24
42.60
44.03
44.29
23.60
2.37
1.00
0.50
3.79
VSWR
(:1)
492.89
95.45
69.61
60.92
50.18
32.72
1.97
1.40
1.31
5.70
100
90
80
70
60
50
40
30
20
10
0
0
VHP-19
INSERTION LOSS
1000
VHP-19
VSWR
INSERTION LOSS (dB)
VSWR
1000 2000 3000 4000 5000 6000 7000 8000 9000
FREQUENCY (MHz)
100
10
1
0
1000 2000 3000 4000 5000 6000 7000 8000 9000
FREQUENCY (MHz)
Freq.
(MHz)
1.00
500.00
1000.00
1500.00
1800.00
2000.00
2570.00
3000.00
7000.00
9000.00
Insertion
Loss (dB)
100.58
64.74
70.90
45.46
33.17
24.65
2.97
1.09
0.90
4.41
VSWR
(:1)
452.14
88.41
61.83
45.41
34.51
26.04
2.45
1.25
1.59
6.05
110
100
90
80
70
60
50
40
30
20
10
0
0
VHP-26
INSERTION LOSS
1000
VHP-26
VSWR
INSERTION LOSS (dB)
VSWR
1000 2000 3000 4000 5000 6000 7000 8000 9000
FREQUENCY (MHz)
100
10
1
0
1000 2000 3000 4000 5000 6000 7000 8000 9000
FREQUENCY (MHz)
Freq.
(MHz)
1.00
600.00
1000.00
2000.00
2570.00
3050.00
3900.00
4500.00
5500.00
9000.00
Insertion
Loss (dB)
112.38
64.77
64.70
48.15
35.11
23.91
3.01
1.13
1.03
4.06
VSWR
(:1)
775.98
128.90
104.50
76.04
58.12
35.47
2.06
1.32
1.58
6.07
120
INSERTION LOSS (dB)
100
80
60
40
20
0
0
VHP-39
INSERTION LOSS
1000
VHP-39
VSWR
VSWR
1000 2000 3000 4000 5000 6000 7000 8000 9000
FREQUENCY (MHz)
100
10
1
0
1000 2000 3000 4000 5000 6000 7000 8000 9000
FREQUENCY (MHz)
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
ISO 9001 CERTIFIED
Page 2 of 2
