Low Noise Amplifiers
50Ω
600 to 2400 MHz
Features
•
•
•
•
•
EW!
N
ZQLSC-SERIES
high reliability balanced design
noise figure, 0.6 dB typ.
built-in alarm monitoring
TTL alarm output, green/red alarm status LED
voltage regulated/protected DC input
Applications
CASE STYLE: GZ1067
•
•
•
•
low noise receiver
digital cellular base stations
TDMA, CDMA, GSM
DCS, PCS, UMTS
Electrical Specifications (T
AMB
= 25°C)
MODEL
NO.
FREQ.
(MHz)
GAIN
(dB)
Flatness
f
L
- f
U
ZQLSC-1100
600-824
824-849
880-915
915-1100
1400-1850
1850-2000
2000-2400
Typ. Min.
20 17.5
19 17.5
18.5 17
17.5 15
17 13.5
15.6 12.5
13.2 10.5
Typ.
±.75
±.15
±0.2
±0.9
±1.0
±0.5
±1.5
NOISE MAXIMUM POWER INTER-
(dBm)
CEPT
FIGURE
POINT
(dB)
Input
Output
(1 dB Comp.) (no
Max. Typ. Max. Typ. Min. damage)
0.6
0.55
0.55
0.6
1.1
0.7
0.8
1.0
18.5
19
19
19
19
20.5
20
16
16
16
16
17
17
17
10
10
10
10
10
10
10
IP3
dBm
Typ.
32.5
34
35
35.5
37
35
34
VSWR
(:1)
Max.
In
2.0
1.7
1.8
1.8
1.7
1.5
1.6
Out
2.0
1.7
1.8
1.8
1.6
1.6
1.9
DC
POWER
Max.
Volt Current
Typ. (mA)
1
CASE
STYLE
PRICE
$
QTY.
(1-9)
±1.0
±0.3
±0.4
±1.2
±2.5
±1.0
±2.0
24
24
24
24
24
24
24
185
185
185
185
185
185
185
GZ1067
295.00
ZQLSC-2400
0.8 1.15
0.9 1.25
1.1 1.65
GZ1067
295.00
Maximum Ratings
Operating Temperature
Storage Temperature
DC Voltage
1
Outline Drawing
-40°C to 80°C case
-40°C to 60°C ambient
-55°C to 100°C
+18Vmin., 36V max.
Other voltages available in the 6.5 to 60V range, please contact factory.
Alarm Functions
Normal:
TTL low output (0 to 0.8V), green LED
Alarm:
TTL high output (4 to 5V), red LED
DC & alarm connector:
9-pin male D-sub
Pin Connections
RF input
RF output
DC power input
TTL alarm output
Ground to test alarm, normally open
No connection
Ground
J1
J2
5
1
7*,9*
3,6,8
2,4
*Grounding Pin 7 will sink 75mA of current through Pin 7
creating a high-current alarm condition inside the amplifiers.
A red LED and TTL high output will occur. Pin 7 floats at
+4.3V typ. when open.
*Grounding Pin 9 will sink 2mA of current through pin 9 and
creating a low-current alarm condition inside the amplifier. A
red LED and TTL high output will occur. Pin 9 floats at about
+0.6V typ. when open.
Outline Dimensions (
inch
)
mm
A
B
C
3.75 3.00
.80
95.25 76.20 20.32
D
E
F
.37 1.62 2.95
9.40 41.15 74.93
G
H
J
K
L
M
wt.
.36
.42
.55 2.650
.86 2.000 grams
9.14 10.67 13.97 67.31 21.84 50.80 260
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. A
M93728
ZQLSC-1100 EDB020911
ZQLSC-2400 EDB020910
ZQLSC-SERIES
BLUECELL/TD/CP
040805
Page 1 of 2
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
ISO 9001 & ISO 14001
Certified
Typical Performance Curves at 25°C
ZQLSC-1100
30
28
26
24
22
20
18
16
14
12
10
600
700
ZQLSC-1100
GAIN
30
28
26
24
22
20
18
16
14
12
10
1400
1600
ZQLSC-SERIES
ZQLSC-2400
ZQLSC-2400
GAIN
GAIN (dB)
800
900
1000
1100
GAIN (dB)
1800
2000
2200
2400
FREQUENCY (MHz)
FREQUENCY (MHz)
2.0
NOISE FIGURE (dB)
ZQLSC-1100
NOISE FIGURE
2.0
NOISE FIGURE (dB)
ZQLSC-2400
NOISE FIGURE
1.5
1.5
1.0
1.0
0.5
0.5
0.0
600
700
800
900
1000
1100
FREQUENCY (MHz)
0.0
1400
1600
1800
2000
2200
2400
FREQUENCY (MHz)
40
ZQLSC-1100
IP3
50
45
ZQLSC-2400
IP3
35
IP3 (dBm)
IP3 (dBm)
600
700
800
900
1000
1100
40
35
30
25
20
FREQUENCY (MHz)
20
1400
1600
1800
2000
2200
2400
FREQUENCY (MHz)
30
25
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
ISO 9001 & ISO 14001
Certified
Page 2 of 2
