ZRL-1200 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> ZRL-1200

ZRL-1200: DescriptionLow Noise Amplifier 50з 650 to 1200 MHz; CategoryWireless rf/communication Radio frequency and microwave; File Size181KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric View All

ZRL-1200 Overview

Low Noise Amplifier 50з 650 to 1200 MHz

ZRL-1200 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Mini-Circuits
package instruction	MODULE(UNSPEC)
Reach Compliance Code	unknow
Other features	SMA
Characteristic impedance	50 Ω
structure	COAXIAL
Gain	25 dB
Maximum input power (CW)	10 dBm
JESD-609 code	e0
Number of functions	1
Maximum operating frequency	1200 MHz
Minimum operating frequency	650 MHz
Maximum operating temperature	60 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	MODULE(UNSPEC)
power supply	12 V
RF/Microwave Device Types	NARROW BAND MEDIUM POWER
Terminal surface	Tin/Lead (Sn/Pb)
Maximum voltage standing wave ratio	1.25

Preview

Download Datasheet

View All

High IP3

Low Noise Amplifier

50Ω 650 to 1200 MHz

Maximum Ratings

Operating Temperature

Storage Temperature

DC Voltage

-40°C to 80°C case

-40°C to 60°C ambient

-55°C to 100°C

+17V max.

EW!

ZRL-1200

Features

•

high IP3, +46 dBm typ.

low noise figure, 2.0 dB typ.

broadband flat gain response

internal voltage regulated

over voltage and transient protected

low noise, high dynamic range

analog/digital cellular

PCS, GSM, TDMA, CDMA

UHF television

driver amplifier

CASE STYLE: FJ893

PRICE: $119.95 ea. QTY (1-9)

Applications

Outline Drawing

FREQ.

RANGE

(MHz)

- f

650-1200

800-950

Electrical Specifications (T

AMB

=25°C)

GAIN

(dB)

Flatness

Typ. Min.

27.5 25

28 26

Typ.

±0.6

±0.4

Max. Typ. Max.

±1.0

±0.8

2.0

3.0

NOISE MAXIMUM POWER

(dBm)

FIGURE

(dB)

Output

(1 dB Comp.)

Typ. Min.

24.3 23.5

Input

(no

damage)

+10

INTER-

CEPT

POINT

IP3

dBm

Typ.*

VSWR

(:1)

Typ.

Out

DIRECTIVITY

(dB)

POWER

Max.

Volt

Current

Typ. (mA)

550

Typ.

1.20 1.25

1.20 1.20

* 1MHz tone spacing

Other voltages available in the 6.5 to 17V range, please contact factory.

ZRL-1200

GAIN

NOISE FIGURE (dB)

GAIN (dB)

3.0

2.5

2.0

1.5

1.0

0.5

0.0

600

ZRL-1200

NOISE FIGURE

Outline Dimensions (

inch

)

2.00 3.75

.80 3.00

50.80 95.25 20.32 76.20

.26 1.00

.51

6.60 25.40 12.95

.22

5.59

.19 3.374 1.624

4.83 85.70 41.25

.26

6.60

—

.19

4.83

.156

.44

3.96 11.18

wt.

.10 grams

2.54

135

600

700

800

900

1000

1100

1200

700

800

900

1000

1100

1200

FREQUENCY (MHz)

ZRL-1200

IP3

IP3 (dBm)

600

ZRL-1200

VSWR

1.5

INPUT

OUTPUT

1.4

VSWR

700

800

900

1000

1100

1.3

1.2

1.1

1.0

650

760

870

980

1090

1200

FREQUENCY (MHz)

Mini-Circuits

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

ISO 9001 CERTIFIED

REV. E

M92817

ZRL-1200

EDB010904/2

BLUEC/TD/CP

040608
