MT16LSDT1664AY-133B1 datasheet, PDF

Datasheet> All Categories > storage> storage> MT16LSDT1664AY-133B1

MT16LSDT1664AY-133B1: DescriptionSynchronous DRAM Module, 16MX64, 5.4ns, CMOS, MO-161, DIMM-168; Categorystorage storage; File Size710KB，26 Pages; ManufacturerMicron Technology; Websitehttp://www.mdtic.com.tw/; Environmental Compliance

Download Datasheet Parametric Compare View All

MT16LSDT1664AY-133B1 Overview

Synchronous DRAM Module, 16MX64, 5.4ns, CMOS, MO-161, DIMM-168

MT16LSDT1664AY-133B1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Micron Technology
Parts packaging code	DIMM
package instruction	DIMM,
Contacts	168
Reach Compliance Code	compli
ECCN code	EAR99
access mode	DUAL BANK PAGE BURST
Maximum access time	5.4 ns
Other features	AUTO/SELF REFRESH
JESD-30 code	R-XDMA-N168
JESD-609 code	e4
memory density	1073741824 bi
Memory IC Type	SYNCHRONOUS DRAM MODULE
memory width	64
Number of functions	1
Number of ports	1
Number of terminals	168
word count	16777216 words
character code	16000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	65 °C
Minimum operating temperature
organize	16MX64
Package body material	UNSPECIFIED
encapsulated code	DIMM
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
self refresh	YES
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Gold (Au)
Terminal form	NO LEAD
Terminal location	DUAL
Maximum time at peak reflow temperature	30
Base Number Matches	1

Preview

Download Datasheet

View All

64MB (x64, SR), 128MB (x64, DR)

168-PIN SDRAM UDIMM

SYNCHRONOUS

DRAM MODULE

Features

•

168-pin, dual in-line memory module (DIMM)

PC100- and PC133- compliant

Utilizes 125 MHz and 133 MHz SDRAM components

Unbuffered

64MB (8 Meg x 64), 128MB (16 Meg x 64)

Single +3.3V power supply

Fully synchronous; all signals registered on positive

edge of system clock

Internal pipelined operation; column address can

be changed every clock cycle

Internal SDRAM banks for hiding row access/

precharge

Programmable burst lengths: 1, 2, 4, 8, or full page

Auto Precharge, includes CONCURRENT AUTO

PRECHARGE and Auto Refresh Modes

Self Refresh Mode: 64ms, 4,096-cycle refresh

(15.625µs refresh interval)

LVTTL-compatible inputs and outputs

Serial Presence-Detect (SPD)

Gold edge contacts

MT8LSDT864A – 64MB

MT16LSDT1664A – 128MB

For the latest data sheet, please refer to the Micron



Web

site:

www.micron.com/products/modules

Figure 1: 168-Pin DIMM (MO-161)

Standard 1.375in. (34.93mm)

Low Profile 1.125in. (28.58mm)

Options

• Package

168-pin DIMM (standard)

168-pin DIMM (lead-free)

• Memory Clock/CAS Latency

7.5ns (133 MHz)/CL = 2

7.5ns (133 MHz)/CL = 3

10ns (100 MHz)/CL = 2

• PCB

Standard 1.375in. (34.93mm)

Low Profile 1.125in. (28.58mm)

NOTE:

Marking

-13E

-133

-10E

See page 2 note

Table 1:

Timing Parameters

SETUP

TIME

1.5

2ns

HOLD

TIME

0.8

1ns

CL = CAS (READ) latency

ACCESS TIME

MODULE

CLOCK

MARKING FREQUENCY CL = 2 CL = 3

-13E

-133

-10E

133 MHz

100 MHz

5.4ns

–

9ns

–

5.4ns

7.5ns

1. Contact Micron for product availability.

Table 2:

Address Table

64MB

128MB

4 (BA0, BA1)

64Mb (8 Meg x 8)

4K (A0–A11)

512 (A0–A8)

2 (S0, S2; S1, S3)

4 (BA0, BA1)

64Mb (8 Meg x 8)

4K (A0–A11)

512 (A0–A8)

1 (S0, S2)

Refresh Count

Device Banks

Device Configuration

Row Addressing

Column Addressing

Module Ranks

pdf: 09005aef812230b2, source: 09005aef81037690

SD8_16C8_16x64AG.fm - Rev. C 7/04 EN

PRODUCTS AND SPECIFICATIONS DISCUSSED HEREIN ARE SUBJECT TO CHANGE BY MICRON WITHOUT NOTICE.
