BY296 THRU BY299S
FAST RECOVERY SILICON RECTIFIER
Reverse Voltage -
100 to 1000 Volts
Forward Current -
2.0 Amperes
Features
Fast recovery diodes
Diffused junction
High current capability
The plastic material carries U/L recognition 94V-0
Terminals: Axial leads
Polarity: Color band denotes cathode
Mounting Instruction
Min. distance from body to soldering point, 4mm
Max. solder temperature, 350
Max. soldering time: 3.5 Sec.
Do not bend lead at a point closer than 3mm to the body
DIM ENSIONS
DIM
A
B
C
D
inches
Min.
0.283
0.189
0.048
1.000
Max.
0.374
0.208
0.051
-
Min.
7.20
4.80
1.20
25.40
mm
Max.
9.50
5.30
1.30
-
Note
Maximum Ratings and Electrical Characteristics
Ratings at 25
ambient temperature unless otherwise specified.
Symbols
BY296
BY297
BY298
BY299
BY299S
Units
Peak repetitive and non recurrent reverse voltage
Forward current, R load at T
amb
=50
8.3mS peak forward surge current at T
j
=25
Recurrent peak forward current (A)
Maximum forward voltage drop at I
F
=2.0A
Maximum reverse current at V
RRM
at 25
Maximum reverse recovery time (Note 1)
Maximum thermal resistance (I=10mm)
Operating and storage temperature range
Note:
(1) Reverse recovery test conditions: I
F
=0.5A, I
R
=1.0A, I
rr
=0.25A
V
RRM
I
(AV)
I
FSM
I
FRM
V
F
I
R
T
rr
R
JA
100
200
400
2.0
70.0
10.0
1.3
10.0
250
30.0
-65 to +125
800
1000
Volts
Amps
Amps
Amps
Volts
A
nS
/W
T
J
, T
STG
1
