Chip Resistor Array
晶片排列电阻器
Feature (特性)
• High density, more than 1 resistors in one small case
高度密集, 多个电阻在一个表贴封装中
• Improvement of placement efficiency
装配效率高
• Superior solderability
优越焊锡性
• Tape/Reel packaging is suitable for automatic placement machine
编带卷装适合自动化机器
• Application: Master board, CD & DVD Rom, Hard Disk, RAM
硬盘、
内存、
主板等
应用于
CD、
DVD、
www.royalohm.com
Equivalent Circuit Diagram (等效电路图)
2D02/2D03/2C02/2F01
4
4
3
3
4D02/4D03/4DP3/4C02/4C03/4F01
8
8
7
7
6
6
5
5
16
16P8
15 16 15 14 13 12 11 10
14 13 12 11 10 9
9
Derating Curve (
降功率曲线
)
Percnet raed load (%)
负½½比率(%)
2D02/4D02
2D03/4D03
2C02/4C02/4C03
2F01/4F01
R1
R1
R2
R2
R1
R1
R2
R2
R3
R3
R4
R4
R1 R2 R1 R2 R3 R4 R5 R6 R7 R8
R3 R4 R5 R6 R7 R8
1
1
2
2
1
1
2
2
3
3
4
4
1
2
13
24
35
46
57
68
7
8
R1=R2
R1=R2=R3=R4
R1=R2=R3=R4=R5=R6=R7=R8
Ambient temperature (环境温度)(°C)
Dimensions in mm (外观尺寸)
2D02/2D03
4D02/4D03/4DP3
Convex Terminal type
凸式电极
16P8
Concave Terminal
凹式电极
2C02
4C02/4C03
Flat Terminal
平式电极
2F01
4F01
*The 16P8 series of Anti-sulfuration products are available in particular.
*16P8
系列抗硫化产品可特別提供
Type
类型
2D02 0402*2
4D02 0402*4
2D03 0603*2
4D03/4DP3 0603*4
16P8
2C02 0402*2
4C02 0402*4
4C03 0603*4
2F01 0201*2
4F01 0201*4
Dimensions
尺寸
（mm）
A1
A2
/
0.30±0.05
/
0.50±0.15
0.30±0.05
/
/
/
/
/
0.33±0.10
0.40±0.05
0.60±0.15
0.65±0.15
0.45±0.05
/
/
/
0.30±0.10
0.20±0.10
L
1.00±0.10
2.00±0.10
1.60±0.15
3.20±0.20
4.00±0.20
1.00±0.10
2.00±0.10
3.20±0.20
0.80±0.10
1.40±0.10
W
1.00±0.10
1.00±0.10
1.60±0.15
1.60±0.20
1.60±0.15
1.00±0.10
1.00±0.10
1.60±0.20
0.60±0.10
0.60±0.10
T
0.35±0.10
0.45±0.10
0.50±0.10
0.50±0.10
0.45±0.10
0.35±0.10
0.45±0.10
0.60±0.10
0.35±0.10
0.35±0.10
B
0.15±0.05
0.20±0.15
0.30±0.10
0.30±0.15
0.30±0.15
0.15±0. 10
0.15±0.10
0.30±0.20
0.15±0.10
0.15±0.10
P
0.65±0.05
0.50±0.05
0.80±0.05
0.80±0.10
0.50±0.05
/
/
/
0.50±0.05
0.40±0.05
G
0.25±0.10
0.30±0.15
0.25±0.10
0.30±0.15
0.40±0.15
0.30±0.10
0.30±0.10
0.40±0.10
0.15±0.10
0.15±0.10
Chip Resistor Array
www.royalohm.com
晶片排列电阻器
Ratings (规格)
Type
类型
2D02
4D02
2D03
4D03
4DP3
16P8
2C02
4C02
4C03
2F01
4F01
Power rating
per element
70°C
1/16W
1/16W
1/16W
1/16W
1/10W
1/16W
1/16W
1/16W
1/10W
1/20W
1/20W
Max Working
Voltage
最大工½
电压
50V
50V
50V
50V
50V
50V
50V
50V
50V
12.5V
12.5V
Max Overload
Voltage
最大过负荷
电压
100V
100V
100V
100V
100V
100V
100V
100V
100V
25V
25V
Dielectric
Withstanding
Voltage
绝缘耐压
100V
100V
100V
300V
300V
300V
100V
100V
300V
/
/
Resistance
Range
阻值范围
±5%，
±1%
10Ω~1MΩ
10Ω~1MΩ
10Ω~1MΩ
1Ω~1MΩ
1Ω~1MΩ
1Ω~1MΩ
10Ω~1MΩ
10Ω~1MΩ
1Ω~1MΩ
10Ω~1MΩ
10Ω~1MΩ
Temperature
Coefficient
温度系数
PPM/°C
±200
±200
±200
≥10Ω:±200
<10Ω:±400
≥10Ω:±200
<10Ω:±400
≥10Ω:±200
<10Ω:±400
±200
±200
≥10Ω:±200
<10Ω:±400
±200
±200
-55°C~+125°C
<50mΩ
1A
-55°C~+155°C
<50mΩ
1A
Operating
Temperature
工½温度范围
Resistance Value
of Jumper
零欧姆电阻
阻值
Rated Current
of Jumper
零欧姆电阻额
定电流
Performance Specification (性½)
Short-time overload
Insulation Resistance
Dielectric withstanding voltage
Terminal bending
Soldering heat
Solderability
短时间过负荷
绝缘耐压
耐焊接热
可焊性
端子弯曲
绝缘电阻
± (2.0%±0.1Ω)
2F01: 1%: ±1%+0.05Ω, 5%: ±2%+0.05Ω
≥1000MΩ
No evidence of flashover mechanical damage, arcing or insulation break down.
无击穿
,
飞弧及可见机械性损伤
±
(1.0%+±0.05Ω）
ΔR/R ≤ ± (1.0%+0.05Ω)
Coverage must be over 95%.
ΔR/R ≤ ± (1.0%+0.05Ω)
2F01: 1%: ±0.5%+0.05Ω, 5%:±1%+0.05Ω
± (3.0%±0.1Ω)
2F01: 1%:±2%+0.1Ω, 5%: 3.0%±0.1Ω
± (3.0%±0.1Ω)
2F01: 1%: ±2%+0.1Ω, 5%: 3.0%±0.1Ω
Rapid change of temperature
温度快速变化
Load life in humidity
Load life
湿度寿½
负½½寿½
Ordering Procedure (Example: 2F01 1/20W ±5% 10K T/R-10000)
订购方式
(例如: 2F01 1/20W ±5% 10K T/R-10000)
2 F 0 1
Product Type (
产品类型
):
Fill-in 4 digits with the Chip
resistor type as follow (
填四½
数表示产品类型
)
：
2F01, 4F01, 2D02, 2D03, 4D03,
4D02, 4DP3, 2C02, 4C02, 4C03,
16P8
W M J 0 1 0 3 T C E
Resistance Value (阻值):
5% (E-24 series) :
the 1
st
digit is “0”, the 2
nd
& 3
rd
digits are for the
significant figures of the resistance and the 4
th
indicate the numbers of zeros following
5%
产品
(E-24
系列阻值
):
第
1
½数是
0，第 2、3
½数表示阻值的有
效数，第
4
½表示有几个
0);
1%( E-96 series):
the 1
st
to 3
rd
digits are for the significant
figures of the resistance and the 4
th
indicate
the numbers of zeros following
1%
产品
(E-24, E-96
系列阻值
):
第
1-3
½数表示阻值的有效数，第
4
½数
表示有几个
0).
Packing Qty.
(
包装数量
)
4=4,000pcs
5=5,000pcs
C=10,000pcs
D=20,000pcs
E=15,000pcs
Special Feature (特征):
E = Lead Free (standard)
(
无铅标准品
)
Packing Type (包装类型):
T=T/R
（编带
/
卷带）
B=Bulk in Poly bag
（散装
/
袋装）
C=Bulk in cassette
（散装
/
盒装）
Wattage (
功率
):
Fill-in 2 digits with the
codes as follow (
用下列
代码填二½数
):
WM=1/20W
WG=1/16W
WA=1/10W
Tolerance
(
公差
):
F = ±1%
J = ±5%
Remark: For more details/technical support please send email to your contact sales.
