REV
DESCRIPTION
BY APPD
DATE
GCP
02/09/06
RDG
A
RELEASED PER
ECR# 8830
.196 4.98
.261 6.62
.170 4.32
.750 19.05
.224 5.69
.040 1.02
.025
±.001
.200 5.08
.64
±.03
.024 .61
2X
.024 .61
.046
±.003
.004
M
1.17
±.08
A
A
2X .100 2.54
.029
±.002
.004
.74
±.05
M
A
CATALOG NO. 311-010-61411G
NOTES: UNLESS OTHERWISE SPECIFIED
1. MATERIALS:
BODY: BERYLLIUM COPPER PER ASTM B196
CONTACT: BRASS PER ASTM B16
INSULATOR: TEFLON PER ASTM D1710
CLIP RING: BERYLLIUM COPPER PER ASTM B194
2. FINISH:
CLIP RING: .000100 MIN. NICKEL PER QQ-N-290 OVER COPPER FLASH
ALL OTHER METAL PARTS: .000050 MIN. GOLD PER MIL-G-45204 OVER
.000050 MIN. NICLE PER QQ-N-290
RECOMMENDED
HOLE LAYOUT
PER ASME Y14.5M-1994
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
TOLERANCES:
DECIMAL: .XX ± .01 [0.254]
.XXX ± .005 [0.127]
.XXXX ± .XXXX
ANGLES: ± 2°
SCALE: 6:1
NORTHROP GRUMMAN
Winchester Electronics
62 Barnes Industrial Road North
Wallingford, CT 06492
CUSTOMER
DRAWING
DRAWN
GCP
APPROVED
XXX
DATE APPROVED
02/09/06
RDG
DATE APPROVED
XX/XX/XX XXX
DATE
02/09/06
DATE
XX/XX/XX
KNURLED 31 SERIES RECEPTACLE
REV
A
SD311-010-61411
SHT
1
OF
1
A
June 2006 - This drawing became the property of Winchester Electronics Corporation, Wallingford, CT.
