2.0 AMPS. Surface Mount Schottky Barrier Rectifiers
SMB/DO-214AA
Features
For surface mounted application
Easy pirk and place
Metal to silicon rectifier, majority carrier conduction
Low power loss, high efficiency
High current capability, low VF
High surge current capability
Plastic material used carriers Underwriters
Laboratory Classigication 94V-0
Meet MSL level 1, per J-STD-020D,
lead free maximum peak of 260℃
Epitaxial construction
High temperature soldering:
260℃/10 seconds at terminals
Green compound with suffix "G" on packing
code & prefix "G" on datecode.
SS22 - SS215
Mechanical Data
Case: Molded plastic
Terminals: Pure tin plated, lead free.
Polarity: Indicated by cathode band
Packaging: 12mm tape per EIA STD RS-481
Weight: 0.093 grams
Ordering Information (example)
Part No.
SS22
Package
SMB
Packing
850 / 7" REEL
Packing
code
R5
Green Compound
Packing code
R5G
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current, 8.3 ms Single Half Sine-
wave Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage (Note 1)
IF= 2 A @ 25
℃
@ 100
℃
Maximum DC Reverse
Current at Rated DC
Blocking Voltage
Typical Junction Capecitance (Note 2)
Typical Thermal Resistance
Operating Temperature Range
Storage Temperature Range
Note 1: Pulse Test with PW=300u sec, 1% Duty Cycle
@ T
A
=25
℃
@ T
A
=100℃
@ T
A
=125
℃
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
SS
22
20
14
20
SS
23
30
21
30
SS
24
40
28
40
SS
25
50
35
50
2
50
SS
26
60
42
60
SS
29
90
63
90
SS
210
100
70
100
SS
215
150
105
150
Units
V
V
V
A
A
V
F
0.5
0.4
0.4
0.70
0.65
0.85
0.70
0.1
0.95
0.80
V
mA
mA
mA
pF
O
I
R
C
j
R
θJL
R
θJA
T
J
T
STG
10
-
5
130
17
75
-
5.0
C/W
O
O
- 65 to + 125
- 65 to + 150
- 65 to + 150
C
C
Note 2: Measure at 1MHz and Applied Reverse Voltage of 4.0V D.C.
Version:F12
RATINGS AND CHARACTERISTIC CURVES (SS22 THRU SS215)
FIG.1- MAXIMUM FORWARD CURRENT DERATING
CURVE
PEAK FORWARD SURGE CURRENT
(A)
50
40
30
20
10
0
1
10
100
8.3ms Single Half Sine
Wave JEDEC Method
AT RATED TL
2.5
2.0
1.5
1.0
0.5
0.0
50
60
FIG. 2- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
AVERAGE FORWARD
a
CURRENT (A)
SS22-SS24
SS25-SS215
RESISTIVE OR
INDUCTIVE LOAD
70
80
90
100
110
120
130
140
150
160
LEAD TEMPERATURE .(
o
C)
NUMBER OF CYCLES AT 60 Hz
FIG. 3- TYPICAL FORWARD CHARACTERISTICS
100
TA=25
o
C
INSTANTANEOUS FORWARD
A
CURRENT (A)
INSTANTANEOUS REVERSE
A
CURRENT (mA)
10
100
FIG. 4- TYPICALREVERSE CHARACTERISTICS
SS22-SS24
SS25-SS215
TA=125
10
SS25-SS26
1
1
SS22-SS24
SS29-SS210
0.1
TA=75℃
0.01
TA=25℃
0.1
SS215
PULSE WIDTH=300uS
1% DUTY CYCLE
0.01
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
FORWARD VOLTAGE. (V)
0.001
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLYAGE(%)
FIG. 5- TYPICAL JUNCTION CAPACITANCE
1000
TA25℃
f=1.0MHz
Vsig=50mVp-p
FIG. 6- TYPICAL TRANSIENT THERMAL
CHARCTERISTICS
100
JUNCTION CAPACITANCE (pF)
a
TRANSIENT THERMAL
IMPEDANCE (℃/W)
10
100
10
100
1
SS29-SS215
SS22-SS24
SS25-SS26
10
0.1
1
REVERSE VOLTAGE (V)
0.1
0.01
0.1
1
10
100
T-PULSE DURATION. (sec)
