Table 3 . Electrical and thermal characteristics for LUXEON HR30 at 150mA, T
j
=25°C .
PART NUMBER
L130-xxxxxxHR00001
FORWARD VOLTAGE
[1]
(V
f
)
MINIMUM
5.8
TYPICAL
6.2
MAXIMUM
6.8
TYPICAL TEMPERATURE
COEFFICIENT OF FORWARD
VOLTAGE
[2]
(mV/°C)
-3.0
TYPICAL THERMAL
RESISTANCE—JUNCTION
TO SOLDER PAD (°C/W)
14.0
Notes for Table 3:
1. Lumileds maintains a tolerance of ±0.1V on forward voltage measurements.
2. Measured between 25°C and 85°C.
Absolute Maximum Ratings
Table 4 . Absolute maximum ratings for LUXEON HR30 .
PARAMETER
DC Forward Current
[1, 2]
Peak Pulsed Forward Current
[1, 3]
LED Junction Temperature
[1]
(DC & Pulse)
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
Operating Case Temperature
[1]
LED Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (V
reverse
)
MAXIMUM PERFORMANCE
240mA
350mA
150°C
Class 2 for L130-xxxx00HR00001
Class 3B for L130-xxxx0THR00001
-40°C to 125°C
-40°C to 125°C
JEDEC 020c 260°C
3
LUXEON LEDs are not designed to be driven in reverse bias
Notes for Table 4:
1. Proper current derating must be observed to maintain the junction temperature below the maximum allowable junction temperature.
2. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple,” are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed the maximum peak pulsed forward current
